Stihl 381S
Built: 1959–1963 · Series: 380
More machines from model year 1959
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Stihl 380 – small tractors 381, 381S, 382 and 383 with single- and twin-cylinder diesel engines from 7 to 15 kW, displacement 534 to 1,004 cm³, unladen weight between 690 and 1,030 kg
The 380 series brings together four closely related small tractors: the 381, 381S, 382 and 383 types. The continuous numbering from 381 to 383 shows a model sequence with rising motorisation, while the S suffix on the 381S denotes a separate version within the base 381 type. All four models are built as single- or twin-cylinder diesel tractors with comparatively small displacement, placing them in the lightest class of tractors listed here in the register.
Read on 3 more paragraphs
The register lists four versions here with 7.4 to 14.6 kW from single- and twin-cylinder diesel engines with 534 to 1,004 cm³ displacement. Rated speed lies between 1,890 and 2,000 rpm, unladen weight ranges from 690 to 1,030 kg with lengths from 2,415 to 2,825 mm, widths from 1,250 to 1,470 mm and heights from 1,240 to 1,640 mm.
With unladen weights under a tonne and single- to twin-cylinder engines, the 380 series sits in the smallest tractor class, of the kind used for specialty crops, small sideline farms or municipal maintenance work, where manoeuvrability and low weight mattered more than high pulling power.
When buying used, with engines this small the condition of the injection pump and fuel system, tightness of the crankcase and valve cover, wear on the clutch and gearbox, and corrosion on sheet metal parts and wings are especially important to check. Parts availability for such small tractors is limited and runs mainly through specialist used-parts dealers.
Sources: SpecCodex register, model data: Stihl 380
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 14 hp (10.2 kW)correct |
| Rated speed | 1,890 rpmcorrect |
| Cylinders | 1correct |
| Displacement | 763 cm³correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 2,630 mmcorrect |
|---|---|
| Width | 1,470 mmcorrect |
| Height | 1,600 mmcorrect |
| Wheelbase | 1,750 mmcorrect |
| Ground clearance | 420 mmcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 6/1-Getriebecorrect |
| Forward gears | 6correct |
| Front tyres | 4.50-15correct |
| Rear tyres | 8.00-24 AScorrect |
| Top speed | 20 km/hcorrect |
Working data
| Fuel tank capacity | 18 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 150correct |
Other data
| PTO speed | 900 rpmcorrect |
|---|
Frequently asked questions
How much power does the Stihl 381S have?
The Stihl 381S delivers 14 hp.
What engine does the Stihl 381S have?
1 cylinders, 763 cm³ displacement, Diesel.
How fast does the Stihl 381S go?
Top speed is 20 km/h.
What are the dimensions of the Stihl 381S?
2,630 mm × 1,470 mm × 1,600 mm.
When was the Stihl 381S built?
Production years: 1959–1963.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
