Someca 480-8 (TD) – specifications
Built: 1981–1982 · Series: GOLD-RIBBON SERIE
The 480-8 (TD) from Someca is part of the GOLD-RIBBON series. Production: 1981–1982. The engine delivers 48 hp (35.3 kW), has 3 cylinders, with a displacement of 2,592 cm³. Torque is 152 Nm. Rated speed is 2,600 rpm. The machine is 2,910 mm long, 1,790 mm wide and 2,225 mm high. The unladen weight is 1,810 kg. The wheelbase measures 1,953 mm. Ground clearance is 455 mm. Top speed is 25 km/h. Transmission: 8 V/2 R or 12 V/3 R. The engine is water-cooled. Tyres: front 6.00-16 ASF (TD: 7.50-20 AS), rear 12.4-28 AS. The fuel is diesel. The bore measures 100 mm. The stroke is 110 mm. The compression ratio is 17:1. Maximum torque is reached at 1,600 rpm. Construction: unit construction (no separate frame). The GOLD-RIBBON SERIE series covers 36 models. Rated output within it ranges from 25 to 145 hp; the 480-8 (TD) sits in the lower part of that range with 48 hp. Its immediate neighbours are the 470 (TD) below it with 46 hp and the 500 SPECIAL (TD) above it with 50 hp. Unladen weight within it ranges from 1,070 to 5,650 kg; here the 480-8 (TD) sits in the lower part of that range with 1,810 kg. 92 Someca models across 8 series are on record.
Data for the version built 1981–1982 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 1981
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Someca Gold Ribbon: the Fiat range built for export, from the Someca 250 (DT) to the 1300 SUPER (DT), 18.4 to 106.6 kW, two- to six-cylinder engines with water cooling
After 1965, Someca built only Fiat designs under licence. The "Gold Ribbon" range, created for export markets, particularly Britain, bundled these Fiat-based models of the late 1960s and 1970s under Someca's own name and trim.
Read on 4 more paragraphs
The register lists 36 live models, from the Someca 250 (DT) to the 1300 SUPER (DT), built between 1968 and around 1983. Output ranges from 18.4 to 106.6 kW, weight from 1,070 to 5,650 kg, displacement from 1,559 to 7,412 cm3 across two-, three-, four- and six-cylinder engines.
The Gold Ribbon range thus covers practically the entire Fiat-Someca power spectrum of those years, from a compact two-cylinder up to the large six-cylinder 1300 model. Technically, these tractors largely match the equivalent ranges sold in parallel under the Fiat name.
In 1983 Someca was fully absorbed into the Fiatagri division, which became Fiat New Holland in 1993 and later CNH Global — an endpoint that closes out the Gold Ribbon era.
The huge power spread from 18.4 to 106.6 kW means several categories of the ISO 730 three-point linkage occur within the Gold Ribbon range: the small two-cylinder models mostly Category 0 or I, the large six-cylinders already Category II. On a specific example, the actual hitch category should therefore be checked before buying new implements, rather than relying on the model name alone.
Sources: SpecCodex register, model data: Someca Gold Ribbon
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 48 hp (35.3 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Torque | 152 Nmcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 2,592 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 110 mmcorrect |
| Compression ratio | 17correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,910 mmcorrect |
|---|---|
| Width | 1,790 mmcorrect |
| Height | 2,225 mmcorrect |
| Wheelbase | 1,953 mmcorrect |
| Ground clearance | 455 mmcorrect |
| Unladen weight | 1,810 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 8 V/2 R or 12 V/3 Rcorrect |
| Front tyres | 6.00-16 ASF (TD: 7.50-20 AS)correct |
| Rear tyres | 12.4-28 AScorrect |
| Top speed | 25 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Frequently asked questions
Where this model stands
Power-to-weight ratio: 19.5 kW/t (35 kW / 1.8 t)
Power class: Universal (40–100 hp)
Stronger than 32% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
