Sdf Lamborghini 230 VICTORY

Built: 1999–2001 · Series: Victory-Baureihe

More machines from model year 1999

Source: https://www.lectura-specs.com/en/model/agricultural-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 230 VICTORY, Sdf Lamborghini offers a model from the Victory series. Production: 1999–2001. The engine delivers 230 hp (169.3 kW), has 6 cylinders, with a displacement of 7,146 cm³. Torque is 890 Nm. Rated speed is 2,350 rpm. The machine is 5,360 mm long, 2,670 mm wide and 3,225 mm high. The unladen weight is 8,350 kg. The wheelbase measures 3,089 mm. Ground clearance is 540 mm. Top speed is 40 km/h. Transmission: 40 V/40 R. The engine is water-cooled. Tyres: front 520/70 R 34 AS, rear 580/70 R 42 AS. The fuel is Diesel / Biodiesel. The bore measures 108 mm. The stroke is 130 mm. Maximum torque is reached at 1,350 rpm. Construction: unit construction (no separate frame). Rated output across the Sdf Lamborghini range ranges from 52 to 260 hp; the 230 VICTORY sits at the top of that range with 230 hp. Its immediate neighbours are the 200 Champion below it with 195 hp and the 260 VICTORY above it with 260 hp. Rated output across the Sdf Lamborghini range ranges from 38.2 to 191.2 kW; here the 230 VICTORY sits at the top of that range with 169.3 kW. 10 Sdf Lamborghini models across 4 series are on record.

Lamborghini Victory series: heavy agricultural tractors from Cento/Pieve di Cento, from the 230 VICTORY to the 260 VICTORY, 169.3 to 191.2 kW, approved for diesel and biodiesel

Lamborghini Trattori was founded in 1948 by Ferruccio Lamborghini in Cento and has been part of the SAME group since 1972, which builds the tractors at the Pieve di Cento plant. This page collects the Victory series, from the 230 VICTORY to the 260 VICTORY; the leading number gives the approximate horsepower.

Read on 3 more paragraphs

The register lists 2 versions from 169.3 to 191.2 kW from six-cylinder diesel engines of 7,146 cm³ displacement and 890 to 1,010 Nm of torque at 2,350 rpm, able to run on either diesel or biodiesel. Kerb weights range from 8,350 to 8,450 kg, lengths from 5,130 to 5,360 mm, widths from 2,490 to 2,670 mm, with a height of 3,225 mm.

Tractors of this power class rank among Lamborghini's large tractors for the heaviest tillage, cultivator work and hauling large trailer loads; the biodiesel approval was aimed at operations producing their own fuel from oilseed crops or wanting to rely on renewable feedstocks, an option that mattered most to large arable farms and contractors running high annual hours.

When buying a used example, check operating hours and the service history of engine, turbocharger and injection system, the condition of clutch and gearbox, the tightness of the hydraulics, and corrosion on frame, cab and wings; on biodiesel-fuelled examples it is also worth checking fuel lines and seals, which need to be suited to the different fuel.

Sources: SpecCodex register, model data: Lamborghini Victory-Baureihe, Lamborghini Trattori (manufacturer)

Technical data

Engine

Fuel	Diesel / Biodieselcorrect
Power	230 hp (169.3 kW)correct
Rated speed	2,350 rpmcorrect
Torque	890 Nmcorrect
Speed at max. torque	1,350 rpmcorrect
Cylinders	6correct
Displacement	7,146 cm³correct
Bore	108 mmcorrect
Stroke	130 mmcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	5,360 mmcorrect
Width	2,670 mmcorrect
Height	3,225 mmcorrect
Wheelbase	3,089 mmcorrect
Ground clearance	540 mmcorrect
Unladen weight	8,350 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	40 V/40 Rcorrect
Front tyres	520/70 R 34 AScorrect
Rear tyres	580/70 R 42 AScorrect
Top speed	40 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 20.3 kW/t (169 kW / 8.3 t)

Power class: Heavy (> 180 hp)

Stronger than 94% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Sdf Lamborghini 230 VICTORY have?

The Sdf Lamborghini 230 VICTORY delivers 230 hp.

How much does the Sdf Lamborghini 230 VICTORY weigh?

The unladen weight is 8,350 kg.

What engine does the Sdf Lamborghini 230 VICTORY have?

6 cylinders, 7,146 cm³ displacement, Diesel / Biodiesel.

How fast does the Sdf Lamborghini 230 VICTORY go?

Top speed is 40 km/h.

What are the dimensions of the Sdf Lamborghini 230 VICTORY?

5,360 mm × 2,670 mm × 3,225 mm.

When was the Sdf Lamborghini 230 VICTORY built?

Production years: 1999–2001.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
