Scania Cv DC16 084A
Built: 2014-2025 · Series: DC16
More machines from model year 2014
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Scania DC16 – 16-litre V8 diesel engine from Södertälje: EPA-certified, 405 to 566 kW, Tier 4 Final/Interim, maximum torque up to 3,233 Nm, for nonroad applications
Scania CV is the Swedish commercial vehicle and engine manufacturer headquartered in Södertälje. The DC16 is the company's large V8 engine with around 16 litres of displacement, derived from a bore and stroke of 130 and 154 mm respectively; the EPA engine-family codes such as EY9XL16.4DAA or JY9XL16.4DAA confirm this displacement via the code 16.4.
Read on 3 more paragraphs
The register lists here 6 versions with 405 to 566 kW rated output at 2,000 to 2,100 rpm. Maximum torque ranges from 2,828 to 3,233 Nm at 1,300 to 1,500 rpm. The engines are certified to Tier 4 (Final or Phase-in) and to Interim Tier 4, and split across the 130 to 560 kW and above 560 to 900 kW power categories. Forced induction is by waste-gate or variable-geometry turbocharger.
As a heavy eight-cylinder, the DC16 covers the upper power segment for construction and mining machinery, cranes and stationary power generation, where Scania competes with Cummins, MTU and Volvo Penta; the 405 to 566 kW range spans applications from heavy wheel loaders to standby generator sets.
On a used purchase, operating hours and the service history of the injection system count, along with the condition of the turbocharger, particularly on the variable-geometry versions, the tightness of the charge-air ducting, and on Tier 4 Final engines the function of the exhaust aftertreatment. Cooling system and parts supply run through the Scania sales network.
Sources: SpecCodex register, model data: Scania CV DC16, Scania (manufacturer)
Technical data
Engine
| Engine code | 2 257 386correct |
|---|---|
| Engine family | EY9XL16.4DAAcorrect |
| Fuel | 7-15 ppm Ultra Low Sulfur Dieselcorrect |
| Rated output | 493 kWcorrect |
| Power band | 130<=kW<=560correct |
| Rated speed | 2,100 rpmcorrect |
| Maximum torque | 3,233 N·mcorrect |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 8correct |
| Cylinder layout | V layoutcorrect |
| Bore | 130 mmcorrect |
| Stroke | 154 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
| Turbocharger type | Variable Geometry Turbochargercorrect |
| Charge-air cooling | aircorrect |
| Emissions stage | Tier 4 (Final or Phase In)correct |
Origin and approval
| Version | 2 257 386correct |
|---|---|
| Sales region | bothcorrect |
Frequently asked questions
How much power does the Scania Cv DC16 084A have?
The Scania Cv DC16 084A delivers 493 kW.
When was the Scania Cv DC16 084A built?
Production years: 2014-2025.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
