SAME (SLH) 35 DT

Q: How much power does the SAME (SLH) 35 DT have?

The SAME (SLH) 35 DT delivers 35 hp.

Q: What engine does the SAME (SLH) 35 DT have?

4 cylinders, 1,490 cm³ displacement, Diesel.

Q: What are the dimensions of the SAME (SLH) 35 DT?

2,960 mm × 1,240 mm × 2,035 mm.

Built: 1992–2003 · Series: SOLARIS-Baureihe

More machines from model year 1992

Source: https://www.technikboerse.com/haendler/ritter-maschinen-gmbh

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The SAME (SLH) 35 DT is a model in the SOLARIS series. Production: 1992–2003. The engine delivers 35 hp (25.7 kW), has 4 cylinders, with a displacement of 1,490 cm³. Torque is 84.9 Nm. Rated speed is 4,000 rpm. The machine is 2,960 mm long, 1,240 mm wide and 2,035 mm high. The unladen weight is 1,140 kg. The wheelbase measures 1,630 mm. Ground clearance is 345 mm. Top speed is 25 km/h. Transmission: 12 V/12 R. The engine is water-cooled. Tyres: front 7.00-12 AS, rear 320/70 R 20 AS. The fuel is diesel. The bore measures 78 mm. The stroke is 78 mm. The compression ratio is 18:1. Maximum torque is reached at 2,060 rpm. Construction: unit construction (no separate frame). The SOLARIS-Baureihe series covers 3 models. Rated output within it ranges from 25 to 42 hp; the 35 DT sits in the middle of that range with 35 hp. Its immediate neighbours are the 25 DT below it with 25 hp and the 45 DT above it with 42 hp. Unladen weight within it ranges from 1,005 to 1,140 kg; here the 35 DT sits at the top of that range with 1,140 kg. 21 SAME (SLH) models across 7 series are on record.

SAME Solaris range: collective page of compact four-wheel-drive tractors from the shared SLH platform, from the Solaris 25 DT to 45 DT, three- and four-cylinder diesels, 18 to 31 kW

The Solaris range is a line of compact four-wheel-drive tractors built on the shared technical platform of the SDF brands SAME, Lamborghini and Hürlimann (SLH), produced from the 1990s onward. The model numbers 25, 35 and 45 rank the range by power class, and the DT suffix stands throughout for Doppia Trazione, four-wheel drive; all three versions in the register are four-wheel-drive models. In hilly terrain and on small, fragmented plots, the manoeuvrable Solaris models benefit from their tight turning radius.

Read on 3 more paragraphs

The register lists 3 versions with 18.4 to 30.9 kW from three- and four-cylinder diesel engines of 1,118 to 1,490 cm³, unladen weights of 1,005 to 1,140 kg, lengths of 2,690 to 3,030 mm, widths of 1,120 to 1,255 mm and heights of 1,960 to 2,155 mm; torque ranges from 59.8 to 100.2 Nm at rated speeds of 3,000 to 4,000 rpm.

Compact tractors in this power class take on tasks on smaller holdings, in orchards and vineyards, and in municipal grounds care for which larger standard tractors are too unwieldy; the Solaris range competes there with comparable compact models from Deutz-Fahr, Kubota and Iseki.

When buying used, condition of the high-revving diesel engine, the clutch and four-wheel drive under load, and the hydraulics and lift all matter; spare parts run through the SAME-Deutz-Fahr dealer network.

Sources: SpecCodex register, model data: SAME Solaris

Technical data

Engine

Fuel	dieselcorrect
Power	35 hp (25.7 kW)correct
Rated speed	4,000 rpmcorrect
Torque	84.9 Nmcorrect
Speed at max. torque	2,060 rpmcorrect
Cylinders	4correct
Displacement	1,490 cm³correct
Bore	78 mmcorrect
Stroke	78 mmcorrect
Compression ratio	18correct
Cooling	water-cooledcorrect

Dimensions and weights

Length	2,960 mmcorrect
Width	1,240 mmcorrect
Height	2,035 mmcorrect
Wheelbase	1,630 mmcorrect
Ground clearance	345 mmcorrect
Unladen weight	1,140 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	12 V/12 Rcorrect
Front tyres	7.00-12 AScorrect
Rear tyres	320/70 R 20 AScorrect
Top speed	25 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 22.5 kW/t (26 kW / 1.1 t)

Power class: Compact (< 40 hp)

Stronger than 21% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the SAME (SLH) 35 DT have?

The SAME (SLH) 35 DT delivers 35 hp.

How much does the SAME (SLH) 35 DT weigh?

The unladen weight is 1,140 kg.

What engine does the SAME (SLH) 35 DT have?

4 cylinders, 1,490 cm³ displacement, Diesel.

How fast does the SAME (SLH) 35 DT go?

Top speed is 25 km/h.

What are the dimensions of the SAME (SLH) 35 DT?

2,960 mm × 1,240 mm × 2,035 mm.

When was the SAME (SLH) 35 DT built?

Production years: 1992–2003.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
