SAME (SLH) ARGON 50 (DT)

Built: 1993–2004 · Series: ARGON-Baureihe

More machines from model year 1993

Source: https://www.heavyequipmentspecs.com/tractors/same-minitauro-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The SAME (SLH) ARGON 50 (DT) belongs to the ARGON series. Production: 1993–2004. The engine delivers 50 hp (36.8 kW), has 3 cylinders, with a displacement of 3,000 cm³. Torque is 172 Nm. Rated speed is 2,350 rpm. The machine is 3,380 mm long, 1,640 mm wide and 2,245 mm high. The unladen weight is 2,090 kg. The wheelbase measures 1,975 mm. Ground clearance is 390 mm. Top speed is 30 km/h. Transmission: 16 V/8 R and 24 V/12 R. The engine is air-cooled. Tyres: front 7.50-16 ASF (DT: 11.2 R 20 AS), rear 14.9 R 28 AS. The fuel is diesel. The bore measures 105 mm. The stroke is 115.5 mm. The compression ratio is 17:1. Maximum torque is reached at 1,600 rpm. Construction: unit construction (no separate frame). The ARGON-Baureihe series covers 3 models. Rated output within it ranges from 50 to 70 hp; the ARGON 50 (DT) sits at the bottom of that range with 50 hp. Its immediate neighbours are the ARGON 60 (DT) above it with 60 hp. Unladen weight within it ranges from 2,090 to 2,600 kg; here the ARGON 50 (DT) sits at the bottom of that range with 2,090 kg. 21 SAME (SLH) models across 7 series are on record.

SAME (SLH) Argon range – tractors Argon 50 to 70 from the 1990s, 37 to 52 kW, three-cylinder engines of 3,000 cm³, DT four-wheel-drive versions

The Argon range was developed in the 1990s at SAME within the SLH group, the alliance of SAME, Lamborghini and Hürlimann; the models covered here, Argon 50, 60 and 70, carry the DT suffix on the two smaller versions for the doppia trazione four-wheel-drive version. The type number follows the logic typical of SAME, roughly denoting the power class in hp.

Read on 3 more paragraphs

The register lists here 3 versions with 36.8 to 51.5 kW from three-cylinder engines of a uniform 3,000 cm³, torque from 172 to 255 Nm, unladen weights from 2,090 to 2,600 kg, lengths from 3,380 to 3,590 mm, widths from 1,640 to 1,780 mm, heights from 2,245 to 2,305 mm and a rated speed of 2,350 rpm.

With power in the range of 50 to 70 hp, the Argon range covered the lower to mid segment of the SAME line-up and competed with comparable compact and mid-range tractors from Massey Ferguson, Fiat and Deutz-Fahr; as four-wheel-drive versions, the DT models were also suited to sloping terrain such as in vineyards.

On a used Argon, the condition of the clutch and gearbox, the tightness of the hydraulics, rust on the chassis and wings, and, on the DT versions, the condition of the front-axle gearing and drive shafts also count; parts run through the SAME Deutz-Fahr network. The condition of the engine mounts and cab mountings is also worth checking, as wear here leads to increased vibration during operation on tractors of this class.

Sources: SpecCodex register, model data: SAME (SLH) Argon-Baureihe

Technical data

Engine

Fuel	dieselcorrect
Power	50 hp (36.8 kW)correct
Rated speed	2,350 rpmcorrect
Torque	172 Nmcorrect
Speed at max. torque	1,600 rpmcorrect
Cylinders	3correct
Displacement	3,000 cm³correct
Bore	105 mmcorrect
Stroke	115.5 mmcorrect
Compression ratio	17correct
Cooling	air-cooledcorrect

Dimensions and weights

Length	3,380 mmcorrect
Width	1,640 mmcorrect
Height	2,245 mmcorrect
Wheelbase	1,975 mmcorrect
Ground clearance	390 mmcorrect
Unladen weight	2,090 kgcorrect

Drivetrain and chassis

Drive	rear- or four-wheel drivecorrect
Gearbox	16 V/8 R and 24 V/12 Rcorrect
Front tyres	7.50-16 ASF (DT: 11.2 R 20 AS)correct
Rear tyres	14.9 R 28 AScorrect
Top speed	30 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 17.6 kW/t (37 kW / 2.1 t)

Power class: Universal (40–100 hp)

Stronger than 34% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the SAME (SLH) ARGON 50 (DT) have?

The SAME (SLH) ARGON 50 (DT) delivers 50 hp.

How much does the SAME (SLH) ARGON 50 (DT) weigh?

The unladen weight is 2,090 kg.

What engine does the SAME (SLH) ARGON 50 (DT) have?

3 cylinders, 3,000 cm³ displacement, Diesel.

How fast does the SAME (SLH) ARGON 50 (DT) go?

Top speed is 30 km/h.

What are the dimensions of the SAME (SLH) ARGON 50 (DT)?

3,380 mm × 1,640 mm × 2,245 mm.

When was the SAME (SLH) ARGON 50 (DT) built?

Production years: 1993–2004.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
