SAME Deutz Fahr H-86 XA
Built: 2005 · Series: XA-Baureihe
More machines from model year 2005
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Hürlimann XA: the Swiss compact class within the SDF group, from the H-56 XA to the H-90 XA, 41.2 to 62.5 kW, three- and four-cylinder engines with water cooling
The XA series carries on the tradition of the Swiss brand Hürlimann within the SDF group, with the characteristic "H" prefix in model names and a design built around compact, agile tractors.
Read on 4 more paragraphs
The register lists 8 live models, from the H-56 XA to the H-90 XA, built between 1995 and 2014. Output ranges from 41.2 to 62.5 kW, weight from 2,600 to 3,260 kg, displacement from 3,000 to 4,000 cm3, across three- and four-cylinder engines.
The long production span of nearly two decades shows the XA series was continuously developed without losing its basic character as a compact Hürlimann all-rounder.
As one of several XA generations within the SDF group, this series targets operations that value Hürlimann's specific Swiss chassis tradition.
The 30 to 40 km/h top speed recorded in the register shows the XA series was supplied both with a simpler field gearing and with a faster road gearing; when buying used, it is worth matching the fitted gearing to the intended use – field work or more frequent road travel. Checking the actual gearbox ratio against the type plate before a longer road journey avoids surprises with the maximum permitted speed. Like the third XA generation, this series also shares drivetrain components with other SDF group brands, which eases spares supply through the SDF dealer network.
Sources: SpecCodex register, model data: Hürlimann XA-Baureihe
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 83 hp (61 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 318 Nmcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,000 cm³correct |
| Bore | 105 mmcorrect |
| Stroke | 115.5 mmcorrect |
| Compression ratio | 16correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,950 mmcorrect |
|---|---|
| Width | 2,050 mmcorrect |
| Height | 2,460 mmcorrect |
| Wheelbase | 2,185 mmcorrect |
| Ground clearance | 380 mmcorrect |
| Unladen weight | 3,160 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 45V/45Rcorrect |
| Front tyres | 380/70 R 20 AScorrect |
| Rear tyres | 480/70 R 30 AScorrect |
| Top speed | 40 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 19.3 kW/t (61 kW / 3.2 t)
Power class: Universal (40–100 hp)
Stronger than 57% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the SAME Deutz Fahr H-86 XA have?
The SAME Deutz Fahr H-86 XA delivers 83 hp.
How much does the SAME Deutz Fahr H-86 XA weigh?
The unladen weight is 3,160 kg.
What engine does the SAME Deutz Fahr H-86 XA have?
4 cylinders, 4,000 cm³ displacement, Diesel.
How fast does the SAME Deutz Fahr H-86 XA go?
Top speed is 40 km/h.
What are the dimensions of the SAME Deutz Fahr H-86 XA?
3,950 mm × 2,050 mm × 2,460 mm.
When was the SAME Deutz Fahr H-86 XA built?
Production years: 2005.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
