SAME Deutz Fahr 3035E
Built: 2010s · Series: Serie 3E
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
SAME Deutz-Fahr 3035E: compact three-cylinder tractor rated at 31 kW and 1,620 kg weight from the economy Series 3E range
SAME Deutz-Fahr is a brand of the Italian SDF group, headquartered in Treviglio, which brought together the tractor brands SAME, Deutz-Fahr, Lamborghini and Hürlimann. Series 3E forms the more simply equipped economy line within the lower power segment, aimed at smaller and mid-sized farms, orchards and livestock holdings.
Read on 3 more paragraphs
The 3035E is powered by a three-cylinder diesel engine of 2,500 cc, producing 31 kW (42 hp) at 2,000 rpm. At a weight of 1,620 kg, a wheelbase of 1,800 mm and a width of 1,600 mm, the tractor reaches a design top speed of 32 km/h. The hydraulic lift capacity is 1,250 kg, the overall height 2,185 mm and the length 3,229 mm.
A three-cylinder engine of 2.5 litres and roughly 1.6 tonnes of weight marks a compact all-purpose tractor, the kind used for grassland upkeep, yard work and light implements. The 32 km/h top speed sits below the thresholds of both the L and T German driving licence categories for agricultural and forestry tractors. The three-point hitch at this size usually takes category 1 implements, and the power take-off runs at 540 rpm.
Buying a used compact economy model, it is worth checking the lift capacity under load, since the simpler hydraulics on this line are more modestly sized than on higher trim levels. Also worth checking at inspection are the front mounting plate if a front loader was retrofitted, plus tyre condition and the hydraulic hoses.
Sources: SpecCodex-Register: Kennwerte des Modells 3035E
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 42 hp (31 kW)correct |
| Rated speed | 2,000 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 2,500 cm³correct |
Dimensions and weights
| Length | 3,229 mmcorrect |
|---|---|
| Width | 1,600 mmcorrect |
| Height | 2,185 mmcorrect |
| Wheelbase | 1,800 mmcorrect |
| Ground clearance | 400 mmcorrect |
| Unladen weight | 1,620 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 8V / 2Rcorrect |
| Front tyres | 7.50 R 16correct |
| Rear tyres | 12.4 R 28correct |
| Top speed | 32 km/hcorrect |
Working data
| Lifting capacity | 1,250 kgcorrect |
|---|
Where this model stands
Power-to-weight ratio: 19.1 kW/t (31 kW / 1.6 t)
Power class: Universal (40–100 hp)
Stronger than 27% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the SAME Deutz Fahr 3035E have?
The SAME Deutz Fahr 3035E delivers 42 hp.
How much does the SAME Deutz Fahr 3035E weigh?
The unladen weight is 1,620 kg.
What engine does the SAME Deutz Fahr 3035E have?
3 cylinders, 2,500 cm³ displacement, Diesel.
How fast does the SAME Deutz Fahr 3035E go?
Top speed is 32 km/h.
How much does the rear linkage of the SAME Deutz Fahr 3035E lift?
The rear linkage lifts 1,250 kg.
What are the dimensions of the SAME Deutz Fahr 3035E?
3,229 mm × 1,600 mm × 2,185 mm.
When was the SAME Deutz Fahr 3035E built?
Production years: 201?.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
