Renault 58-14 LS
Built: 9/1987–1/1989 · Series: LS-Baureihe
More machines from model year 1987
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Renault LS: the compact entry class of the mid-1980s, 54 to 78 hp, three- and four-cylinder diesels on the same engine base as the RS and TX
The LS series filled out Renault's line-up in the mid-1980s with a more compact entry class below the TX and RS, with noticeably lower weight on a similar engine base.
Read on 4 more paragraphs
The register lists 8 live models, from the 58-12 LS to the 85-14 LS, built between 1985 and 1989. Output ranges from 39.7 to 57.4 kW, or 54 to 78 hp, weight from 2,640 to 3,600 kg, displacement from 3,117 to 4,156 cm3, across three- and four-cylinder engines.
Despite sharing the same displacement base as the RS and TX, LS models consistently weigh less, pointing to simpler cab and chassis specification aimed at smaller and mid-sized farms.
Renault thus positioned the LS series as an affordable route into its engine technology, without the comfort and equipment scope of the larger series.
When buying a used, lighter LS series, clutch and mechanical gearbox condition, the tightness of the lift hydraulics, and rust on the simpler cab and mudguards matter; since the engine and displacement are identical to the RS and TX, parts for the injection system and cooling are widely available, though cab- and chassis-specific parts are scarcer. Parts have run through the Claas parts network since Renault Agriculture's dissolution. PTO and three-point hitch likewise correspond in this power class to ISO 730 Category I to II, at 540 rpm.
Sources: SpecCodex register, model data: Renault LS-Baureihe
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 54 hp (39.7 kW)correct |
| Rated speed | 2,250 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 3,117 cm³correct |
| Bore | 105 mmcorrect |
| Stroke | 120 mmcorrect |
| Compression ratio | 16.6correct |
| Injection pressure | 180 barcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,660 mmcorrect |
|---|---|
| Width | 1,860 mmcorrect |
| Height | 2,460 mmcorrect |
| Wheelbase | 2,240 mmcorrect |
| Ground clearance | 370 mmcorrect |
| Unladen weight | 3,000 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 12V/12R or 24V/24Rcorrect |
| Front tyres | 11.2-24 AScorrect |
| Rear tyres | 14.9-28 AScorrect |
| Top speed | 30 km/hcorrect |
Working data
| Fuel tank capacity | 65 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 182correct |
Other data
| Linkage category | Cat IIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 13.2 kW/t (40 kW / 3 t)
Power class: Universal (40–100 hp)
Stronger than 37% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Renault 58-14 LS have?
The Renault 58-14 LS delivers 54 hp.
How much does the Renault 58-14 LS weigh?
The unladen weight is 3,000 kg.
What engine does the Renault 58-14 LS have?
3 cylinders, 3,117 cm³ displacement, Diesel.
How fast does the Renault 58-14 LS go?
Top speed is 30 km/h.
What are the dimensions of the Renault 58-14 LS?
3,660 mm × 1,860 mm × 2,460 mm.
When was the Renault 58-14 LS built?
Production years: 9/1987–1/1989.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
