Renault 180-94 TZ
Built: 9/1991–9/1997 · Series: 94 er-Baureihe
More machines from model year 1991
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Renault 94 series – large six-cylinder tractors from Renault Agriculture: 160-94 TZ/TX and 180-94 TZ, 110.4 to 125.1 kW, 6,234 cm³, 525 to 598 Nm at 2,350 rpm
Renault Agriculture, the farm-equipment arm of the French Renault group based in Le Mans, built the 94 series as large six-cylinder tractors; from 2003 the division was majority-owned, and from 2008 fully owned, by the farm-machinery group Claas. The 94 series comprises the 160-94 TZ/TX and 180-94 TZ models. The range sat at the top of Renault's line-up of the time and marked the transition to the more powerful tractor generations of the 1990s.
Read on 3 more paragraphs
The register lists here 2 versions with 110.4 to 125.1 kW, or up to 170 hp, from a six-cylinder engine of 6,234 cm³, an unladen weight of 6,237 to 6,275 kg, a length of 4,755 mm, a width of 2,228 mm, a height of 3,160 mm, torque of 525 to 598 Nm and a rated speed of 2,350 rpm.
With its high power and strong torque, the 94 series targeted large arable farms in France and the rest of Western Europe that needed pulling power for heavy tillage and high road speeds. Its strong pulling power also made it sought after for heavy mounted implements and road transport.
Buyers of used units should check the turbocharger and injection system, clutch and gearbox, and the electronics in the cab, as well as the hydraulics and rust on the frame; spares now run through the Claas dealer network, which took over support for the older Renault ranges. Before purchase it is also worth checking the front axle on four-wheel-drive versions and wear on the PTO shaft.
Sources: SpecCodex register, model data: Renault 94er-Baureihe
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 170 hp (125.1 kW)correct |
| Rated speed | 2,350 rpmcorrect |
| Torque | 598 Nmcorrect |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 6,234 cm³correct |
| Bore | 105 mmcorrect |
| Stroke | 120 mmcorrect |
| Compression ratio | 16.5correct |
| Injection pressure | 240 barcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,755 mmcorrect |
|---|---|
| Width | 2,228 mmcorrect |
| Height | 3,160 mmcorrect |
| Wheelbase | 2,803 mmcorrect |
| Ground clearance | 540 mmcorrect |
| Unladen weight | 6,237 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 27 V/27 Rcorrect |
| Forward gears | 27correct |
| Front tyres | 16.9 R 30 AScorrect |
| Rear tyres | 20.8 R 38 AScorrect |
| Top speed | 40 km/hcorrect |
Working data
| Fuel tank capacity | 225 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 352correct |
Other data
| Linkage category | Cat IIIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 20.1 kW/t (125 kW / 6.2 t)
Power class: Large (100–180 hp)
Stronger than 87% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Renault 180-94 TZ have?
The Renault 180-94 TZ delivers 170 hp.
How much does the Renault 180-94 TZ weigh?
The unladen weight is 6,237 kg.
What engine does the Renault 180-94 TZ have?
6 cylinders, 6,234 cm³ displacement, Diesel.
How fast does the Renault 180-94 TZ go?
Top speed is 40 km/h.
What are the dimensions of the Renault 180-94 TZ?
4,755 mm × 2,228 mm × 3,160 mm.
When was the Renault 180-94 TZ built?
Production years: 9/1991–9/1997.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 31 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
