Reisch RSBS-3-13 – specifications
Built: 2020 · Series: Other models
The Reisch RSBS-3-13 is a vehicle built by Reisch. Production: 2020. The vehicle is 14,000 mm long and 2,550 mm wide. The unladen weight is 7,000 kg. The wheelbase measures 9,110 mm. Top speed is 100 km/h. The gross vehicle weight is 39,000 kg. The vehicle runs on 6 wheels. Unladen weight across the Reisch range ranges from 2,220 to 7,900 kg; the RSBS-3-13 sits in the upper part of that range with 7,000 kg. Its immediate neighbours are the 35/24AL below it with 6,900 kg and the RSBS-35/24LK above it with 7,900 kg. Gross vehicle weight across the Reisch range ranges from 10,000 to 43,000 kg; here the RSBS-3-13 sits at the top of that range with 39,000 kg. 12 Reisch models are on record.
Data for the version built 2020 · Data origin: Official register · sources
More machines from model year 2020
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Reisch – other models: the collective page of tipping semi-trailers outside the named ranges, RHKS, RSBS, RTDK and RTW types, gross vehicle weight from 10 to 43 t, lengths up to 14 m
This page gathers the Reisch tipping semi-trailers the register could not assign to a named range. The model '3-Achs-Kippsattelauflieger' names the vehicle type directly as a three-axle tipping semi-trailer; the type codes RHKS, RSBS, RTDK and RTW denote different ranges, followed by number combinations for axle count, length or payload, such as RHKS-31/24SL or RSBS-35/24LK.
Read on 3 more paragraphs
The register lists 12 versions here with kerb weights from 2,220 to 7,900 kg, gross vehicle weights from 10,000 to 43,000 kg, lengths from 7,250 to 14,000 mm and widths from 2,420 to 2,550 mm.
With gross weights up to 43 t and the tipping function in the name, the models on this collective page are tipping semi-trailers for earth, rubble and bulk-material haulage in construction and civil engineering, supplemented by three-axle versions for higher payloads. On the European used market, Reisch tipping semi-trailers are in particular demand among earthworks and recycling firms that need short loading and unloading cycles.
Buying used, check the tipping body for wear and tightness, the hydraulic cylinders and lines, the frame and chassis rails for cracks, the axle units and brake system, and the kingpin and support legs. Spare parts for the tipping hydraulics and running gear run through the Reisch dealer network and independent commercial-vehicle workshops. The wear plates in the tipping area and the condition of the steps and handrails also belong in the inspection.
Sources: SpecCodex register, model data: Reisch (weitere Modelle)
Technical data
Dimensions and weights
| Length | 14,000 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Coupling-to-axle distance | 9,110 mmcorrect |
| Unladen weight | 7,000 kgcorrect |
| Gross vehicle weight | 39,000 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
Used listings – figures from public listings
Between September and October 2026, speccodex recorded 4 public used-machine listings for Reisch RSBS-3-13 on one platform. Asking prices ranged from €13,900 to €39,900 (median €22,200), years of manufacture between 2017 and 2026.
Asking prices are sellers' demands, not achieved sale prices. Basis: public listings, recorded and analysed by speccodex. As of: 22 Nov 2026. Sellers usually do not state whether prices are net or gross.
How much does a used Reisch RSBS-3-13 cost? Asking prices from public listings
Area: Machines › Commercial vehicles
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
