Nordic S3400
Built: 2018-2018 · Series: Other models
More machines from model year 2018
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Nordic – other models: the collective page for Scandinavian curtainside semi-trailers outside the named ranges, a Gardin Trailer, 5 to 10.5 t unladen weight, up to 46 t gross vehicle weight
This page brings together the Nordic trailers that the register could not assign to a named range. The model S350 GARDIN TRAILER uses the Scandinavian word for curtain, denoting a curtainsider semi-trailer with a side-opening tarpaulin; alongside it the register lists types such as the P 330, S 339 and S 342.
Read on 3 more paragraphs
The register lists 9 versions here with unladen weights from 5,000 to 10,500 kg, gross vehicle weights from 30,000 to 46,000 kg, lengths from 9,300 to 14,000 mm and widths from 2,540 to 2,550 mm.
Curtainside semi-trailers of this kind are widespread in European general freight, since the side-opening tarpaulin allows loading and unloading by forklift from either side; Scandinavian road haulage also commonly runs combinations at a higher gross weight than the rest of Europe, which may account for the upper end of this range. Fleet operators favour the type because a single trailer can serve pallet freight, timber and mixed loads alike.
When buying used, check the curtainsider tarpaulin for tears and tension, the roof sheet and bows, the load rails and lashing rings along the sides, the axle assemblies and brake system, and the frame for distortion. The kingpin and fifth-wheel plate need particularly careful checking given the high gross vehicle weights involved, as do the tyres, which wear faster under these loads than in ordinary service.
Sources: Kennwerte der Modelle Nordic
Technical data
Dimensions and weights
| Length | 13,890 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 9,100 mmcorrect |
| Unladen weight | 6,939 kgcorrect |
| Gross vehicle weight | 40,000 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Nordic S3400 weigh?
The unladen weight is 6,939 kg.
What is the gross vehicle weight of the Nordic S3400?
40,000 kg.
Up to what speed is the Nordic S3400 approved?
Approved up to 100 km/h.
What are the dimensions of the Nordic S3400?
13,890 mm × 2,550 mm.
When was the Nordic S3400 built?
Production years: 2018.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
