Nh Geotech M 100

Built: 1996–1999 · Series: M-Baureihe

More machines from model year 1996

Source: https://www.lectura-specs.com/en/model/agricultural-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the M 100, Nh Geotech offers a model from the M series. Production: 1996–1999. The engine delivers 100 hp (73.6 kW), has 6 cylinders, with a displacement of 7,480 cm³. Torque is 403 Nm. Rated speed is 2,200 rpm. The machine is 4,658 mm long, 2,135 mm wide and 2,824 mm high. The unladen weight is 5,029 kg. The wheelbase measures 2,723 mm. Ground clearance is 360 mm. Top speed is 30 km/h. Transmission: 18V/6R and 24V/12R. The engine is water-cooled. Tyres: front 14.9 R 28 AS, rear 18.4 R 38 AS. The fuel is diesel. The bore measures 111.8 mm. The stroke is 127 mm. The compression ratio is 17.5:1. Maximum torque is reached at 1,413 rpm. Construction: unit construction (no separate frame). Injection pressure is 270 bar. The M-Baureihe series covers 4 models. Rated output within it ranges from 100 to 160 hp; the M 100 sits at the bottom of that range with 100 hp. Its immediate neighbours are the M 115 above it with 115 hp. Unladen weight within it ranges from 5,029 to 6,080 kg; here the M 100 sits at the bottom of that range with 5,029 kg. 19 Nh Geotech models across 6 series are on record.

New Holland Geotech M series – six-cylinder tractors of the merger era: 7,480 cc, 73.6 to 117.8 kW, types M 100, M 115, M 135 and M 160

The M series occupied the upper power class of the 1990s New Holland Geotech generation with consistently six-cylinder engines, while the smaller series of the merger era relied on three- and four-cylinders. The four types M 100, M 115, M 135 and M 160, unlike the DT suffix of the smaller ranges, are listed without a separate four-wheel-drive designation and state the power step directly in the type number.

Read on 3 more paragraphs

The register lists 4 versions with 73.6 to 117.8 kW from the consistently 7,480 cc six-cylinder at 2,200 to 2,300 rpm; torque ranges from 403 to 652 Nm. Unladen weights lie between 5,029 and 6,080 kg, lengths between 4,655 and 4,658 mm, width is uniform at 2,135 mm, and heights lie between 2,824 and 2,835 mm.

The M series was aimed at larger arable farms and contractors relying on heavy tillage and transport work, forming the upper end of the New Holland range of these years, in competition with the large Case IH and Deutz-Fahr series. Distribution ran through the existing Ford and New Holland dealer network, which was gradually converted to the new brand identity during this transitional period.

On a used purchase of these large six-cylinders, check operating hours and the service history of the injection pump, the condition of the clutch and gearbox, and the tightness of the hydraulics; parts run through the New Holland network.

Sources: SpecCodex register, model data: New Holland Geotech M-Baureihe, New Holland (CNH, Hersteller)

Technical data

Engine

Fuel	dieselcorrect
Power	100 hp (73.6 kW)correct
Rated speed	2,200 rpmcorrect
Torque	403 Nmcorrect
Speed at max. torque	1,413 rpmcorrect
Cylinders	6correct
Displacement	7,480 cm³correct
Bore	111.8 mmcorrect
Stroke	127 mmcorrect
Compression ratio	17.5correct
Injection pressure	270 barcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	4,658 mmcorrect
Width	2,135 mmcorrect
Height	2,824 mmcorrect
Wheelbase	2,723 mmcorrect
Ground clearance	360 mmcorrect
Unladen weight	5,029 kgcorrect

Drivetrain and chassis

Drive	four-wheel drivecorrect
Gearbox	18V/6R and 24V/12Rcorrect
Front tyres	14.9 R 28 AScorrect
Rear tyres	18.4 R 38 AScorrect
Top speed	30 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 14.6 kW/t (74 kW / 5 t)

Power class: Universal (40–100 hp)

Stronger than 66% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Nh Geotech M 100 have?

The Nh Geotech M 100 delivers 100 hp.

How much does the Nh Geotech M 100 weigh?

The unladen weight is 5,029 kg.

What engine does the Nh Geotech M 100 have?

6 cylinders, 7,480 cm³ displacement, Diesel.

How fast does the Nh Geotech M 100 go?

Top speed is 30 km/h.

What are the dimensions of the Nh Geotech M 100?

4,658 mm × 2,135 mm × 2,824 mm.

When was the Nh Geotech M 100 built?

Production years: 1996–1999.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
