Nh Geotech L 65 (DT)

Built: 1996–1998 · Series: L-Baureihe

More machines from model year 1996

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The L 65 (DT) from Nh Geotech is part of the L series. Production: 1996–1998. The engine delivers 65 hp (47.8 kW), has 4 cylinders, with a displacement of 3,613 cm³. Torque is 198 Nm. Rated speed is 2,500 rpm. The machine is 3,910 mm long, 2,120 mm wide and 2,500 mm high. The unladen weight is 3,910 kg. The wheelbase measures 2,342 mm. Ground clearance is 480 mm. Top speed is 30 km/h. Transmission: 12V/4R, 12V/12R, 20V/12R and 24V/12R. The engine is water-cooled. Tyres: front 7.50-16 ASF (DT: 320/70 R 24 AS), rear 480/70 R 30 AS. The fuel is diesel. The bore measures 100 mm. The stroke is 115 mm. The compression ratio is 17:1. Maximum torque is reached at 1,398 rpm. Construction: unit construction (no separate frame). Injection pressure is 220 bar. The L-Baureihe series covers 4 models. Rated output within it ranges from 60 to 95 hp; the L 65 (DT) sits at the bottom of that range with 65 hp. Its immediate neighbours are the L 60 (DT) below it with 60 hp and the L 75 (DT) above it with 75 hp. Unladen weight within it ranges from 3,400 to 4,190 kg; here the L 65 (DT) sits in the upper part of that range with 3,910 kg. 19 Nh Geotech models across 6 series are on record.

New Holland Geotech L series – compact tractors of the merger era: three- and four-cylinder diesels at 2,931 to 3,908 cc, 44.2 to 69.9 kW, types L 60, L 65, L 75 and L 95 (DT)

The L series emerged after the merger of Ford New Holland with Fiat's agricultural machinery division in the early 1990s and ran into the late 1990s under the New Holland Geotech name before the Geotech suffix was dropped. The four types L 60, L 65, L 75 and L 95 represent the lower to mid power class of this transitional generation, with the number roughly indicating the power step; the DT suffix denotes the four-wheel-drive version.

Read on 3 more paragraphs

The register lists 4 versions with 44.2 to 69.9 kW from three- and four-cylinders of 2,931 to 3,908 cc displacement at a consistent 2,500 rpm; torque ranges from 187 to 284 Nm. Unladen weights lie between 3,400 and 4,190 kg, lengths between 3,910 and 4,000 mm, widths between 2,020 and 2,120 mm, and heights between 2,500 and 2,550 mm.

The L series was aimed at smaller to medium arable and grassland farms and formed the lower end of the New Holland range of these years, in direct competition with comparable series from Deutz-Fahr, Same and Massey Ferguson. Distribution ran through the existing Ford and New Holland dealer network, which was gradually converted to the new brand identity during this transitional period.

On a used purchase, check the condition of the clutch and gearbox, the tightness of the hydraulics, and corrosion on wings and steering knuckles; on DT four-wheel-drive versions also the front-axle drive and joints, with parts running through the New Holland network.

Sources: SpecCodex register, model data: New Holland Geotech L-Baureihe, New Holland (CNH, Hersteller)

Technical data

Engine

Fuel	dieselcorrect
Power	65 hp (47.8 kW)correct
Rated speed	2,500 rpmcorrect
Torque	198 Nmcorrect
Speed at max. torque	1,398 rpmcorrect
Cylinders	4correct
Displacement	3,613 cm³correct
Bore	100 mmcorrect
Stroke	115 mmcorrect
Compression ratio	17correct
Injection pressure	220 barcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	3,910 mmcorrect
Width	2,120 mmcorrect
Height	2,500 mmcorrect
Wheelbase	2,342 mmcorrect
Ground clearance	480 mmcorrect
Unladen weight	3,910 kgcorrect

Drivetrain and chassis

Drive	rear- or four-wheel drivecorrect
Gearbox	12V/4R, 12V/12R, 20V/12R and 24V/12Rcorrect
Front tyres	7.50-16 ASF (DT: 320/70 R 24 AS)correct
Rear tyres	480/70 R 30 AScorrect
Top speed	30 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct

Where this model stands

Power-to-weight ratio: 12.2 kW/t (48 kW / 3.9 t)

Power class: Universal (40–100 hp)

Stronger than 44% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Nh Geotech L 65 (DT) have?

The Nh Geotech L 65 (DT) delivers 65 hp.

How much does the Nh Geotech L 65 (DT) weigh?

The unladen weight is 3,910 kg.

What engine does the Nh Geotech L 65 (DT) have?

4 cylinders, 3,613 cm³ displacement, Diesel.

How fast does the Nh Geotech L 65 (DT) go?

Top speed is 30 km/h.

What are the dimensions of the Nh Geotech L 65 (DT)?

3,910 mm × 2,120 mm × 2,500 mm.

When was the Nh Geotech L 65 (DT) built?

Production years: 1996–1998.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
