New Holland TM190 2WD – specifications

Series: Other models

Build year not documented · Data origin: Reference work (Wikipedia/Wikibooks), Directory data · sources

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The New Holland TM190 is a tractor from the TM series, configured with two driven axles. Positioned as a heavy-duty field tractor, this model occupies the upper power range of the series. The design is based on a six-cylinder engine with a displacement of 7,472.5 cm³, equipped with a turbocharger and intercooler. The vehicle's length of 5,935 mm and width of 2,495 mm require appropriate attention to vehicle dimensions during road travel and transport on low-loaders.

Engine output of 194 PS at a rated speed of 2,200 rpm forms the basis for working speed. The maximum torque of 751 Nm is available already at 1,400 rpm, meaning the tractor can develop high tractive forces at low engine speeds without heavily loading the engine. The curb weight of 7,510 kg ensures good traction, while the ground clearance of 470.2 mm allows for overcoming obstacles and adapting to various soil conditions. The large fuel tank capacity of 397.8 l permits long operating times without frequent refueling stops, thereby increasing productivity during large-scale operations.

The powershift transmission offers 17 forward gears and 6 reverse gears, allowing precise speed adjustment for different soil cultivation tasks. The lifting capacity of 7,750 kg on the Category II/III three-point hitch enables the attachment of heavy implements such as plows or cultivators. The pump flow rate of 120 l/min supplies hydraulic attachments with sufficient oil volume for rapid control movements. PTO speeds of 540E and 1,000 rpm cover the spectrum for common attachments, while the PTO power of 160 hp determines efficiency in power transmission to rotating tools.

New Holland – other models: the collective page of tractors outside the named ranges, from the Fiat heritage (80-66, 110-90) through the Ford 40 and 70 series (7740, 8340, 8670) to the 9x82 and T9, 14 to 457 kW, NEF

This page gathers the New Holland tractors the register could not assign to a named range – and it shows the brand's three roots: Fiat of Turin, Ford of Basildon and Versatile of Winnipeg. New Holland, founded in 1895 as a farm-machinery works in Pennsylvania, was joined with Ford Tractor in 1986 into Ford New Holland and bought by Fiat in 1991, which merged with Case as CNH from 1999; the blue tractors of the 1990s therefore carry three type logics. The Fiat types such as 80-66 and 110-90 give the hp class before and the series after the hyphen; the Ford 40 (5640 to 8340) and 70 (8670 to 8970) series from Basildon and Antwerp give the power in the middle digits and the series in the last, with SLE and SL as equipment lines; the articulated 9282 to 9882 and the later T9 come from Winnipeg and Fargo. From 2007 the T logic applies: T4 to T9 as ranges, the following digits as power (T6.140 about 140 hp). The engines are Fiat's 8000 series, Ford's Genesis, FPT's NEF and Cursor and Cummins in the articulated tractors.

Read on 3 more paragraphs

The register lists here 578 versions with 13.8 to 457 kW from three- to six-cylinders of 954 to 15,001 cm³, PTO outputs from 15 to 530 hp, lift capacities from 574 to 8,900 kg, unladen weights from 652 to 25,401 kg, gross weights from 3,000 to 18,000 kg, lengths from 2,700 to 8,005 mm and widths from 1,082 to 4,060 mm.

New Holland is Europe's second-largest tractor brand after John Deere and in the top three in Italy, Spain, France, Britain and Turkey; the brand also carries the specialist tractors from Jesi and the Boomer compact class from Japan.

On used tractors, clutch and shuttle count on Fiat types, electronics and powershift on the Ford 40 and 70 series, transmission and tyres on the articulated tractors, and on the T ranges operating hours, common-rail injection and exhaust aftertreatment; parts run through CNH.

Sources: SpecCodex register, model data: New Holland (weitere Modelle), New Holland Agriculture (manufacturer)

Technical data

Engine

Power194 hp (142.7 kW)correct
Rated speed2,200 rpmcorrect
Torque751 Nmcorrect
Speed at max. torque1,400 rpmcorrect
Cylinders6correct
Displacement7,472.5 cm³correct
AspirationTurbocharged, air-to-air intercooledcorrect
Coolant capacity26.1 lcorrect
Engine oil capacity19.3 lcorrect

Dimensions and weights

Length5,935 mmcorrect
Width2,495 mmcorrect
Height3,055 mmcorrect
Wheelbase2,843.8 mmcorrect
Ground clearance470.2 mmcorrect
Unladen weight7,510 kgcorrect

Drivetrain and chassis

Gearbox18 V/6 R or 19 V/6 Rcorrect
Gearbox typePower Command powershift transmissioncorrect
Forward gears17correct
Reverse gears6correct

Working data

Lifting capacity7,750 kgcorrect
Pump flow120 l/mincorrect
Hydraulic oil capacity100.3 lcorrect
Fuel tank capacity397.8 lcorrect

Other data

Linkage categoryCat II/IIIcorrect
PTO output160 hpcorrect
PTO speed540E/1000 rpmcorrect
System voltage12 Vcorrect

Where this model stands

Power-to-weight ratio: 19 kW/t (143 kW / 7.5 t)

Power class: Heavy (> 180 hp)

Stronger than 90% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the New Holland TM190 have?

The New Holland TM190 delivers 194 hp.

How much does the New Holland TM190 weigh?

The unladen weight is 7,510 kg.

What engine does the New Holland TM190 have?

6 cylinders, 7,472 cm³ displacement.

What is the PTO output of the New Holland TM190?

PTO output is 160 hp. PTO speeds: 540E/1000 rpm.

How much does the rear linkage of the New Holland TM190 lift?

The rear linkage lifts 7,750 kg.

What are the dimensions of the New Holland TM190?

5,935 mm × 2,495 mm × 3,055 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Shift the gearbox cold and warm — jumps only show up at temperature.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
