New Holland TD5.95
Built: Year not documented · Series: TD5
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
New Holland TD5.95: four-cylinder tractor of the TD5 range with 73 kW output, 6,000 kg gross vehicle weight and a 2,280 mm wheelbase
New Holland places the TD5 range, like the TD4 range, in the mid segment of general-purpose tractors, between compact yard tractors and the large T-range field tractors.
Read on 3 more paragraphs
The TD5.95 is powered by a water-cooled four-cylinder diesel engine of 3.4 litres, delivering 73 kW at 2,300 rpm, roughly 99 hp. Unladen weight is 3,740 kg against a gross vehicle weight of 6,000 kg, with a length of 4,320 mm, a height of 2,665 mm and a width of 1,920 mm; the machine therefore carries considerably more payload than its unladen weight suggests, while staying compact enough for normal-width tracks.
General-purpose tractors of this size cover tillage, transport and power-take-off work at the standard speeds of 540 or 1,000 rpm on medium holdings. The gap between gross vehicle weight and unladen weight sets how much front hydraulic implement or front ballast is possible without overloading the front axle; the combination of 73 kW and a 6,000 kg gross vehicle weight makes the TD5.95 versatile, from pure drawbar work to towing a trailer.
When buying used, check the brakes, which see more load at a gross vehicle weight of 6,000 kg than on lighter models, along with the tightness of hydraulic cylinders and the condition of the driveline guards. Rust on load-bearing panels points to long periods stored outdoors, as does uneven tyre wear from one-sided loading.
Sources: SpecCodex-Register: Kennwerte des Modells New Holland TD5.95, New Holland (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 99 hp (73 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,400 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 4,320 mmcorrect |
|---|---|
| Width | 1,920 mmcorrect |
| Height | 2,665 mmcorrect |
| Wheelbase | 2,280 mmcorrect |
| Ground clearance | 464 mmcorrect |
| Unladen weight | 3,740 kgcorrect |
| Gross vehicle weight | 6,000 kgcorrect |
Working data
| Fuel tank capacity | 121 lcorrect |
|---|
Where this model stands
Power-to-weight ratio: 19.5 kW/t (73 kW / 3.7 t)
Power class: Universal (40–100 hp)
Stronger than 65% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the New Holland TD5.95 have?
The New Holland TD5.95 delivers 99 hp.
How much does the New Holland TD5.95 weigh?
The unladen weight is 3,740 kg.
What is the gross vehicle weight of the New Holland TD5.95?
6,000 kg.
What engine does the New Holland TD5.95 have?
4 cylinders, 3,400 cm³ displacement, Diesel.
What are the dimensions of the New Holland TD5.95?
4,320 mm × 1,920 mm × 2,665 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
