Navistar A285
Built: 2012 · Series: Other models
More machines from model year 2012
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Navistar Heavy Duty – other on-highway engines: the collective page of the A range outside the named models, EPA certification data from the MaxxForce era 2012 to 2016, 200 to 550 kW for International trucks
Navistar, headquartered in Lisle, Illinois, operated until the majority takeover by Volkswagen subsidiary Traton in 2021 as International Truck and Engine Corporation, an independent maker of heavy trucks under the International brand. This page gathers the on-highway engines from the US EPA certification data that the register could not assign to a named range; every model designation from A200 to A450MT belongs to the A range, and the engine-family codes consistently contain the manufacturer code NVX. The 2012 to 2016 model years fall in the period when Navistar still developed its own truck engines under the MaxxForce name, before the group switched to Cummins engines in 2017 because of problems with its own exhaust aftertreatment approach.
Read on 3 more paragraphs
The register lists here 45 versions with 200 to 550 kW rated output at 1,600 to 2,600 rpm, with electronic direct injection and diesel as fuel. Maximum torque ranges from 540 to 1,850 Nm at speeds of 900 to 1,600 rpm.
The A range covered the heavy and medium-heavy truck segment of Navistar's International models and competed directly with Cummins, Detroit and PACCAR MX engines; the well-known series problems with the in-house exhaust-treatment approach in this era are among the reasons Navistar later abandoned its own engine programme and, as part of Traton today, again relies on outside engines.
On a used purchase from these model years, what matters especially is the service history of the exhaust aftertreatment and any modifications made, the condition of the injection system and turbocharger, the cooling system and charge-air cooler, and matching the engine-family code to the unit actually fitted; spares run through the International/Navistar dealer network.
Sources: SpecCodex register, model data: Navistar Heavy Duty (weitere Straßenmotoren, EPA-Zertifizierungsdaten), Navistar (manufacturer)
Technical data
Engine
| Engine code | 2,141correct |
|---|---|
| Engine family | CNVXH04660GA; DNVXH04660GA; ENVXH05700GA; FNVXH05700GAcorrect |
| Engine families | CNVXH04660GA; DNVXH04660GA; ENVXH05700GA; FNVXH05700GAcorrect |
| Fuel | dieselcorrect |
| Rated output | 212.5 kW (= 285 bhp)correct |
| Rated speed | 2,200 rpmcorrect |
| Maximum torque | 860 ft·lbfcorrect |
| Speed at max. torque | 1,300 rpmcorrect |
| Operating cycle | dieselcorrect |
| Injection | electronic direct injectioncorrect |
| Aspiration | two-stage turbocorrect |
Origin and approval
| Built from | 2012correct |
|---|---|
| Built to | 2015correct |
| Model year from | 2012correct |
| Model year to | 2015correct |
Other data
| Application | MHDDcorrect |
|---|
Frequently asked questions
How much power does the Navistar A285 have?
The Navistar A285 delivers 212 kW.
When was the Navistar A285 built?
Production years: 2012.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 19 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
