Müller Mitteltal T3 KOMPAKT
Built: 2005 · Series: T3
More machines from model year 2005
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Müller-Mitteltal T3 – low-loader range from Baiersbronn with five versions, gross vehicle weights from 26,000 to 28,000 kg, lengths from 10,600 to 11,650 mm, kerb weights from 6,070 to 6,930 kg
Müller-Mitteltal, based in Baiersbronn, builds low-loader trailers for transporting construction machinery and heavy equipment. The T3 range is listed in the register in five versions, from the base T3 through the T3 DF to the T3 KOMPAKT, T3 KOMPAKT 30.0 and T3 PROFI 30,0 variants.
Read on 3 more paragraphs
The register lists five versions with kerb weights from 6,070 to 6,930 kg and gross vehicle weights from 26,000 to 28,000 kg. Lengths run from 10,600 to 11,650 mm, and widths from 2,520 to 2,550 mm.
As a tandem low-loader, the T3 range is designed to carry excavators, wheel loaders and other construction machinery up to around 28 tonnes, and is used mainly by construction and earthmoving firms and plant hire companies. The T3 range therefore also sits entirely within EU trailer class O4, for trailers with a gross vehicle weight over 10 tonnes. Low-loaders of this weight class are also used by municipalities and recycling firms to transport wheel loaders and compact machinery.
When buying used, a low-loader calls in particular for a check of the ramps and ramp hydraulics, axles, braking system and air suspension, along with the load bed for distortion and corrosion. Spare parts for axles, brakes and hydraulics are supplied by Müller-Mitteltal through its own service network. Also important is the locking mechanism of any extendable frame sections, along with the condition of the wheel chocks and lashing points.
Sources: SpecCodex register, model data: Müller Mitteltal T3, Müller-Mitteltal (manufacturer)
Technical data
Dimensions and weights
| Length | 11,650 mmcorrect |
|---|---|
| Width | 2,520 mmcorrect |
| Wheelbase | 6,440 mmcorrect |
| Unladen weight | 6,700 kgcorrect |
| Gross vehicle weight | 28,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Müller Mitteltal T3 KOMPAKT weigh?
The unladen weight is 6,700 kg.
What is the gross vehicle weight of the Müller Mitteltal T3 KOMPAKT?
28,000 kg.
Up to what speed is the Müller Mitteltal T3 KOMPAKT approved?
Approved up to 100 km/h.
What are the dimensions of the Müller Mitteltal T3 KOMPAKT?
11,650 mm × 2,520 mm.
When was the Müller Mitteltal T3 KOMPAKT built?
Production years: 2005.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
