Metallwerk Creussen Unitrak H 19

Q: How much power does the Metallwerk Creussen Unitrak H 19 have?

The Metallwerk Creussen Unitrak H 19 delivers 15 hp.

Q: What engine does the Metallwerk Creussen Unitrak H 19 have?

1 cylinders, 681 cm³ displacement, Diesel.

Q: What are the dimensions of the Metallwerk Creussen Unitrak H 19?

3,300 mm × 1,710 mm × 1,370 mm.

Built: 1954–1955 · Series: MWC

More machines from model year 1954

Source: https://www.agrarheute.com/technik/insektenfreundliches-maeh

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Unitrak H 19 from Metallwerk Creussen is part of the MWC series. Production: 1954–1955. The engine delivers 15 hp (13.2 kW), has 1 cylinder, with a displacement of 681 cm³. Rated speed is 1,800 rpm. The machine is 3,300 mm long, 1,710 mm wide and 1,370 mm high. The unladen weight is 990 kg. The wheelbase measures 2,140 mm. Ground clearance is 330 mm. Top speed is 17.1 km/h. Transmission: 4/4. The engine is air-cooled. Tyres: front 8-24, rear 5,5-16. The fuel is diesel. Construction: semi-frame construction. Rated output across the Metallwerk Creussen range ranges from 12 to 15 hp; the Unitrak H 19 sits at the top of that range with 15 hp. Its immediate neighbours are the Unitrak UD 12 below it with 12 hp. Rated output across the Metallwerk Creussen range ranges from 8.83 to 13.2 kW; here the Unitrak H 19 sits at the top of that range with 13.2 kW. 3 Metallwerk Creussen models across 2 series are on record.

Metallwerk Creußen MWC – small single-cylinder diesels from Upper Franconia: MWC 15 Treff and Unitrak H 19, 681 cm³, 13.2 kW, 950 to 990 kg, lengths 2,450 to 3,300 mm, widths 1,500 to 1,710 mm

Metallwerk Creußen, based in Creußen in Upper Franconia, built small, single-cylinder diesel tractors, represented in the register here by the MWC 15 Treff and the Unitrak H 19. The name MWC stands for Metallwerk Creußen itself, while Unitrak served as a separate model name for a further design from the firm. Both vehicles share the concept of a compact single-cylinder diesel tractor for smaller farms.

Read on 3 more paragraphs

The register lists 2 versions with 13.2 kW from single-cylinder engines of 681 cm³, unladen weights of 950 to 990 kg, lengths of 2,450 to 3,300 mm, widths of 1,500 to 1,710 mm and heights of 1,250 to 1,370 mm at a rated speed of 1,800 rpm.

With their low weight and compact build, such small single-cylinder diesels were an alternative to draught animals and larger tractors for smallholdings and special crops in Franconia, where narrow plots and sloped terrain favoured a manoeuvrable, light tractor.

When buying used, check the condition of the single-cylinder diesel engine, especially compression and the injection pump, the tightness of clutch and gearbox, the condition of brakes and steering, and rust on the bodywork and frame; since this is a small manufacturer, parts are mainly sourced through collectors and enthusiasts of classic small tractors.

Sources: SpecCodex register, model data: Metallwerk Creußen MWC

Technical data

Engine

Fuel	dieselcorrect
Power	15 hp (13.2 kW)correct
Rated speed	1,800 rpmcorrect
Cylinders	1correct
Displacement	681 cm³correct
Cooling	air-cooledcorrect

Dimensions and weights

Length	3,300 mmcorrect
Width	1,710 mmcorrect
Height	1,370 mmcorrect
Wheelbase	2,140 mmcorrect
Ground clearance	330 mmcorrect
Unladen weight	990 kgcorrect

Drivetrain and chassis

Drive	front-wheel drivecorrect
Gearbox	4/4correct
Front tyres	8-24correct
Rear tyres	5, 5-16correct
Top speed	17.1 km/hcorrect

Origin and approval

Construction	semi-frame constructioncorrect

Where this model stands

Power-to-weight ratio: 13.3 kW/t (13 kW / 1 t)

Power class: Compact (< 40 hp)

Stronger than 6% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.
