Metallwerk Creussen MWC 15 Treff
Built: 1953–1955 · Series: MWC
More machines from model year 1953
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Metallwerk Creußen MWC – small single-cylinder diesels from Upper Franconia: MWC 15 Treff and Unitrak H 19, 681 cm³, 13.2 kW, 950 to 990 kg, lengths 2,450 to 3,300 mm, widths 1,500 to 1,710 mm
Metallwerk Creußen, based in Creußen in Upper Franconia, built small, single-cylinder diesel tractors, represented in the register here by the MWC 15 Treff and the Unitrak H 19. The name MWC stands for Metallwerk Creußen itself, while Unitrak served as a separate model name for a further design from the firm. Both vehicles share the concept of a compact single-cylinder diesel tractor for smaller farms.
Read on 3 more paragraphs
The register lists 2 versions with 13.2 kW from single-cylinder engines of 681 cm³, unladen weights of 950 to 990 kg, lengths of 2,450 to 3,300 mm, widths of 1,500 to 1,710 mm and heights of 1,250 to 1,370 mm at a rated speed of 1,800 rpm.
With their low weight and compact build, such small single-cylinder diesels were an alternative to draught animals and larger tractors for smallholdings and special crops in Franconia, where narrow plots and sloped terrain favoured a manoeuvrable, light tractor.
When buying used, check the condition of the single-cylinder diesel engine, especially compression and the injection pump, the tightness of clutch and gearbox, the condition of brakes and steering, and rust on the bodywork and frame; since this is a small manufacturer, parts are mainly sourced through collectors and enthusiasts of classic small tractors.
Sources: SpecCodex register, model data: Metallwerk Creußen MWC
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 15 hp (13.2 kW)correct |
| Rated speed | 1,800 rpmcorrect |
| Cylinders | 1correct |
| Displacement | 681 cm³correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 2,450 mmcorrect |
|---|---|
| Width | 1,500 mmcorrect |
| Height | 1,250 mmcorrect |
| Wheelbase | 1,600 mmcorrect |
| Ground clearance | 400 mmcorrect |
| Unladen weight | 950 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 5/1correct |
| Front tyres | 5.0-16correct |
| Rear tyres | 8-24 / 7-30correct |
| Top speed | 18 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 13.9 kW/t (13 kW / 0.9 t)
Power class: Compact (< 40 hp)
Stronger than 6% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Metallwerk Creussen MWC 15 Treff have?
The Metallwerk Creussen MWC 15 Treff delivers 15 hp.
How much does the Metallwerk Creussen MWC 15 Treff weigh?
The unladen weight is 950 kg.
What engine does the Metallwerk Creussen MWC 15 Treff have?
1 cylinders, 681 cm³ displacement, Diesel.
How fast does the Metallwerk Creussen MWC 15 Treff go?
Top speed is 18 km/h.
What are the dimensions of the Metallwerk Creussen MWC 15 Treff?
2,450 mm × 1,500 mm × 1,250 mm.
When was the Metallwerk Creussen MWC 15 Treff built?
Production years: 1953–1955.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 19 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
