Mercedes Benz 4945 10X2
Built: 2019 · Series: Arocs
More machines from model year 2019
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Mercedes-Benz Arocs – Mercedes-Benz Trucks' construction range from Wörth am Rhein since 2013: L, K and LK as chassis variants, engine outputs of 265 to 460 kW, displacements of 10.7 to 15.6 litres
The Arocs is Mercedes-Benz Trucks' construction and heavy-haulage range, introduced in 2013 as a standalone line alongside the Actros and Antos and built at the Wörth am Rhein plant; it took over the previous construction variants of the Actros for tippers, mixers and crane chassis. In the type designation the first digits denote weight class and engine power, the letters the chassis variant: L the standard version, K the tipper, LK a combination of both, B a construction all-wheel-drive variant.
Read on 3 more paragraphs
The register lists 126 versions with engine outputs of 265 to 460 kW, displacements of 10,677 to 15,569 cm³ and six to eight cylinders.
The Arocs covers Mercedes-Benz Trucks' construction segment and competes chiefly with the MAN TGS, the Scania XT and the Volvo FMX; its domain is tippers, concrete mixers, crane and hook-lift vehicles with reinforced frames and a low-range gearbox for construction-site use off made-up roads. Unlike its long-haul sister the Actros, the Arocs is designed for short wheelbases, high ground clearance and a wide range of axle configurations from 6x2 to 10x8, as also seen in the model line-up from 8x4 tippers to 10x8 special chassis.
On a used example, what counts is the condition of the frame and tipper hydraulics, wear on differential locks and the low-range gearbox, corrosion on axles and body mounting points, the condition of the engine and exhaust after-treatment, and parts supply through Mercedes-Benz's dense workshop network.
Sources: SpecCodex register, model data: Mercedes-Benz Arocs, Mercedes-Benz Trucks (Daimler Truck, Hersteller)
Technical data
Engine
| Cylinders | 6correct |
|---|---|
| Displacement | 10,677 cm³correct |
Dimensions and weights
| Length | 9,770 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 7,100 mmcorrect |
| Unladen weight | 16,380 kgcorrect |
| Gross vehicle weight | 49,000 kgcorrect |
Drivetrain and chassis
| Wheels | 10correct |
|---|
Frequently asked questions
How much does the Mercedes Benz 4945 10X2 weigh?
The unladen weight is 16,380 kg.
What is the gross vehicle weight of the Mercedes Benz 4945 10X2?
49,000 kg.
What engine does the Mercedes Benz 4945 10X2 have?
6 cylinders, 10,677 cm³ displacement.
What are the dimensions of the Mercedes Benz 4945 10X2?
9,770 mm × 2,550 mm.
When was the Mercedes Benz 4945 10X2 built?
Production years: 2019.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
