McCormick ZTX 230
Built: Year not documented · Series: ZTX
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
McCormick ZTX 230: a six-cylinder diesel tractor producing 169 kW (230 hp), an unladen weight of 10,040 kg and a width of 2,500 mm, the most powerful segment of the McCormick range.
The ZTX 230 sits at the top of the McCormick range (ARGO Group) and marks the brand's most powerful segment, well above the X model family.
Read on 3 more paragraphs
The ZTX 230 is powered by a six-cylinder diesel engine with 8,300 cm3 displacement, producing 169 kW (230 hp). At an unladen weight of 10,040 kg and a width of 2,500 mm, it is one of the heaviest-built standard tractors in the range, correspondingly large-framed at 3,102 mm tall and 5,335 mm long. Its design top speed is 40 km/h.
Six-cylinder engines above eight litres of displacement and weights over ten tonnes belong to the top power class of field tractors, needed for tilling large arable areas with wide cultivators and ploughs, for heavy trailer combinations and for driving power-hungry PTO-mounted implements. The 2,500 mm width calls for correspondingly wide field tracks and yard gates.
When buying a used ZTX 230, check the clutch, gearbox and rear axle with particular care, since at over ten tonnes and 169 kW, large forces run through the entire drivetrain. The six-cylinder engine calls for a look at the turbocharger, injection system and cooling performance, and the tyres should be checked for even wear, since tractors of this weight class are specifically designed around ground pressure and track stability, especially on soft or uneven ground.
Sources: SpecCodex-Register: Kennwerte des Modells McCormick ZTX 230
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 230 hp (169 kW)correct |
| Cylinders | 6correct |
| Displacement | 8,300 cm³correct |
Dimensions and weights
| Length | 5,335 mmcorrect |
|---|---|
| Width | 2,500 mmcorrect |
| Height | 3,102 mmcorrect |
| Unladen weight | 10,040 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Front tyres | 600/65R28correct |
| Rear tyres | 710/70R38correct |
| Top speed | 40 km/hcorrect |
Working data
| Fuel tank capacity | 570 lcorrect |
|---|
Origin and approval
| Construction | Standardtraktorcorrect |
|---|
Other data
| PTO speed | 750/1000 rpmcorrect |
|---|
Where this model stands
Power-to-weight ratio: 16.8 kW/t (169 kW / 10 t)
Power class: Heavy (> 180 hp)
Stronger than 94% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the McCormick ZTX 230 have?
The McCormick ZTX 230 delivers 230 hp.
How much does the McCormick ZTX 230 weigh?
The unladen weight is 10,040 kg.
What engine does the McCormick ZTX 230 have?
6 cylinders, 8,300 cm³ displacement, Diesel.
How fast does the McCormick ZTX 230 go?
Top speed is 40 km/h.
What are the dimensions of the McCormick ZTX 230?
5,335 mm × 2,500 mm × 3,102 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
