Massey Ferguson MF 7485 – specifications
Built: 2004–2012 · Series: 7400er-Baureihe
The Massey Ferguson MF 7485 belongs to the 7400er series. Production: 2004–2012. The engine delivers 165 hp (121.4 kW), has 6 cylinders, with a displacement of 6,596 cm³. Torque is 626 Nm. Rated speed is 2,200 rpm. The machine is 5,040 mm long, 2,530 mm wide and 3,100 mm high. The unladen weight is 6,870 kg. The wheelbase measures 3,007 mm. Ground clearance is 480 mm. Top speed is 40 km/h. The tank holds 380 litres. The engine is water-cooled. Tyres: front 540/65 R 30 AS, rear 520/85 R 42 AS. The gross vehicle weight is 12,000 kg. The fuel is diesel. Construction: unit construction (no separate frame). The linkage is category II/III. Rated output across the Massey Ferguson range ranges from 10.2 to 375.3 hp; the MF 7485 sits in the middle of that range with 165 hp. Its immediate neighbours are the MF5712SL below it with 163.2 hp and the MF 680 above it with 167.3 hp. Rated output across the Massey Ferguson range ranges from 24 to 375 hp; here the MF 7485 sits in the middle of that range with 165 hp. 1668 Massey Ferguson models across 56 series are on record.
Data for the version built 2004–2012 · Data origin: Official register, Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 2004
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Massey Ferguson 7400 series – built in Beauvais, France: MF 7485 and MF 7495 with six-cylinder engine, 6,596 cm³, 121.4 to 136.2 kW, optional Dyna-VT transmission
The 7400 series represents the more powerful six-cylinder class within the Massey Ferguson model range, built in Beauvais, France, and positioned above the 6400 series. The MF 7485 and MF 7495 models were optionally available with the stepless Dyna-VT transmission, which, unlike the stepped Dyna power-shift gearboxes of the smaller series, allowed continuous ratio change.
Read on 3 more paragraphs
The register lists 2 versions here with 121.4 to 136.2 kW (up to 165 hp) from the six-cylinder diesel engine of 6,596 cm³ displacement, at 2,200 revolutions per minute. Kerb weight is 6,870 kg, at a gross vehicle weight of 12,000 kg, lengths from 5,040 to 5,080 mm, widths from 2,530 to 2,550 mm, a height of 3,100 mm and torque from 626 to 735 Nm.
With the Dyna-VT transmission and high torque, the 7400 series targeted large arable farms and contractors who valued stepless travel speed for both field work and transport alike. In this market segment it competed with stepless large tractors from John Deere, Fendt and Case IH.
When buying used, on the Dyna-VT version the function of the transmission-oil cooling circuit and the electro-hydraulic control is decisive, since repairs to the stepless gearbox are costly. Turbocharger, intercooler and rear-axle bearings of the six-cylinder also warrant checking; spare parts are supplied by AGCO through its dealer network.
Sources: SpecCodex register, model data: Massey Ferguson 7400er-Baureihe, Massey Ferguson (AGCO, Hersteller)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 165 hp (121.4 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 626 Nmcorrect |
| Cylinders | 6correct |
| Displacement | 6,596 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 5,040 mmcorrect |
|---|---|
| Width | 2,530 mmcorrect |
| Height | 3,100 mmcorrect |
| Wheelbase | 3,007 mmcorrect |
| Ground clearance | 480 mmcorrect |
| Unladen weight | 6,870 kgcorrect |
| Gross vehicle weight | 12,000 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | stufenloses Getriebecorrect |
| Front tyres | 540/65 R 30 AScorrect |
| Rear tyres | 520/85 R 42 AScorrect |
| Top speed | 40 km/hcorrect |
Working data
| Fuel tank capacity | 380 lcorrect |
|---|
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Other data
| Linkage category | Cat II/IIIcorrect |
|---|
Frequently asked questions
Where this model stands
Power-to-weight ratio: 17.7 kW/t (121 kW / 6.9 t)
Power class: Large (100–180 hp)
Stronger than 87% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
