Massey Ferguson MF 393 (A)
Built: 1987–1994 · Series: 303er-Baureihe
More machines from model year 1987
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Massey Ferguson 303 series – five versions from the MF 353 to the MF 393, three- and four-cylinder diesels of 2,502 to 4,078 cm³, 34.6 to 58.9 kW, 2,250 to 2,920 kg unladen weight
The range is listed in the register as the Massey Ferguson 303 series and belongs to the European MF-300 model family; it runs from the MF 353 (A) through the MF 363 (A) and MF 373 (A) to the MF 383 (A) and MF 393 (A). The models are fitted with three- or four-cylinder diesel engines, covering the lower to mid power class of this model family.
Read on 3 more paragraphs
The register lists here five versions with 34.6 to 58.9 kW from three- or four-cylinder engines of 2,502 to 4,078 cm³ displacement, torque from 169 to 291 Nm at a rated speed of 2,200 to 2,250 rpm, unladen weights from 2,250 to 2,920 kg, lengths from 3,540 to 3,810 mm, widths from 1,815 to 1,990 mm and heights from 2,240 to 2,325 mm.
As compact all-round tractors, these models positioned themselves between small yard tractors and large field tractors, aimed at medium-sized farms as well as municipalities and contractors needing a versatile, manoeuvrable tractor.
When buying used, the condition of the clutch and gearbox, hydraulic tightness, corrosion on wings and cab floor and completeness of the front hydraulics, where fitted, matter; wear and engine parts are well supplied through the AGCO parts network for Massey Ferguson. In many operations they carried out routine work such as transport, mowing and light tillage for decades. Front-end loader mounts, where fitted, also deserve inspection for cracks and wear.
Sources: SpecCodex register, model data: Massey Ferguson 303er-Baureihe, Massey Ferguson (AGCO, Hersteller)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 80 hp (58.9 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 291 Nmcorrect |
| Speed at max. torque | 1,251 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,078 cm³correct |
| Bore | 101.1 mmcorrect |
| Stroke | 127 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,810 mmcorrect |
|---|---|
| Width | 1,975 mmcorrect |
| Height | 2,325 mmcorrect |
| Wheelbase | 2,341 mmcorrect |
| Ground clearance | 540 mmcorrect |
| Unladen weight | 2,920 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 12V/4Rcorrect |
| Front tyres | 9.00-16 ASF (A: 13.6 R 24 AS)correct |
| Rear tyres | 16.9 R 34 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 20.2 kW/t (59 kW / 2.9 t)
Power class: Universal (40–100 hp)
Stronger than 55% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Massey Ferguson MF 393 (A) have?
The Massey Ferguson MF 393 (A) delivers 80 hp.
How much does the Massey Ferguson MF 393 (A) weigh?
The unladen weight is 2,920 kg.
What engine does the Massey Ferguson MF 393 (A) have?
4 cylinders, 4,078 cm³ displacement, Diesel.
How fast does the Massey Ferguson MF 393 (A) go?
Top speed is 30 km/h.
What are the dimensions of the Massey Ferguson MF 393 (A)?
3,810 mm × 1,975 mm × 2,325 mm.
When was the Massey Ferguson MF 393 (A) built?
Production years: 1987–1994.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
