Manitou 150AETJL
Series: Manitou Boom Lift
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Manitou 150AETJL is an Aerial work platforms from the Manitou Boom Lift series.
It will not go faster than 5 km/h — a working pace, not a travelling one. Unladen, it tips the scales at 5,910 kg.
Manitou Boom Lift – articulated telescopic boom lifts from the French maker Manitou of Ancenis, from the 120AETJC to the 200ATJ, 9.8 to 36.5 kW, operating weights from 4,150 to 10,000 kg, Kubota engines
This page gathers the articulated telescopic boom lifts of Manitou, the French construction equipment maker from Ancenis, which alongside its well-known telehandlers also runs an extensive range of aerial work platforms. The number before the letters denotes the maximum working height in metres, from the 120 range to the 200 range, while AETJ marks the electrically powered articulated telescopic boom with basket jib, ATJ the diesel-powered version, TP the pure telescopic boom, and Bi-Energy models with combined electric and diesel power. MAN'GO denotes the maker's compact mast lift range for indoor and maintenance work. The machines are powered among others by Kubota engines.
Read on 3 more paragraphs
The register lists here 16 versions with 9.8 to 36.5 kW, operating weights from 4,150 to 10,000 kg, basket capacities from 200 to 275 kg, lengths from 4,400 to 8,500 mm and widths from 1,200 to 2,402 mm.
Articulated telescopic boom lifts such as the Manitou range are used for maintenance, construction and installation work at height, where their articulated jibs also clear obstacles and reach hard-to-access spots. Alongside JLG, Genie and Haulotte, Manitou is one of the major suppliers in this market segment.
When buying used, the basket and boom joints should be checked for wear and play, the hydraulic cylinders for lift and telescope function for tightness, and the safety devices such as overload sensors and emergency lowering for correct operation. On the Bi-Energy models it is also worth checking the battery and charging electronics. Spare parts run through the Manitou dealer network, and for the Kubota engines also through Kubota service.
Sources: Kennwerte der Modelle Manitou Boom Lift, Manitou (Hersteller)
Technical data
Engine
| Drive type | electriccorrect |
|---|
Dimensions and weights
| Length | 5,960 mmcorrect |
|---|---|
| Width | 1,750 mmcorrect |
| Ground clearance | 140.2 mmcorrect |
| Unladen weight | 5,910 kgcorrect |
| Platform length | 1,200.1 mmcorrect |
| Platform width | 960.1 mmcorrect |
Drivetrain and chassis
| Top speed | 5.1 km/hcorrect |
|---|---|
| Turning radius | 4,890 mmcorrect |
Working data
| Working height | 15,300 mmcorrect |
|---|---|
| Platform capacity | 230 kgcorrect |
Electrical data
| Battery capacity | 300 Ahcorrect |
|---|---|
| Number of batteries | 2correct |
Other data
| System voltage | 48 Vcorrect |
|---|
Frequently asked questions
How much does the Manitou 150AETJL weigh?
The unladen weight is 5,910 kg.
How fast does the Manitou 150AETJL go?
Top speed is 5.1 km/h.
What are the dimensions of the Manitou 150AETJL?
5,960 mm × 1,750 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 14 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
