MAN 8.240 4X2 BL I890 L CHARISMA II

Built: 2007 · Series: TGL

More machines from model year 2007

Source: truck1.eu

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The MAN 8.240 4X2 BL I890 L CHARISMA II is a model in the TGL series. Production: 2007. The engine has 6 cylinders, with a displacement of 6,871 cm³. The vehicle is 9,150 mm long and 2,400 mm wide. The unladen weight is 6,965 kg. The wheelbase measures 4,500 mm. The gross vehicle weight is 8,600 kg. The vehicle runs on 4 wheels. The TGL series covers 187 models. Unladen weight within it ranges from 3,638 to 11,815 kg; the 8.240 4X2 BL I890 L CHARISMA II sits in the middle of that range with 6,965 kg. Its immediate neighbours are the TGL T 884 F below it with 6,935 kg and the 12.180 4X2 BB above it with 7,025 kg. Gross vehicle weight within it ranges from 7,300 to 12,090 kg; here the 8.240 4X2 BL I890 L CHARISMA II sits in the lower part of that range with 8,600 kg. 5237 MAN models across 68 series are on record.

MAN TGL — the number before the dot is weight, after it power: a light distribution chassis from 7.5 to around 12 tonnes with four- and six-cylinder diesel engines of the D08 family

A MAN TGL 12.250 is rated at 12 tonnes and delivers 250 hp. A 7.150 means 7.5 tonnes and 150 hp; a 12.180 carries the same 12 tonnes with 180 hp. The system is consistent: gross vehicle weight before the dot, engine output after it. Comparing two TGLs, you can see at a glance whether you are looking at the same vehicle with a different engine or at another weight class.

Read on 4 more paragraphs

The TGL is MAN's light range: distribution work in cities and regions, plus lighter construction duty. Together with the larger TGM it covers roughly 7.5 to 26 tonnes. The engines come from the D08 family; the four-cylinder units displace 4.58 litres and produce 150 to 220 hp depending on version.

The series has a long production run behind it. The 12.180 was built from 2005 to 2017; the 12.250 is a more recent version. For the used market that means the same type designation can cover vehicles spanning more than a decade — emissions stage and equipment differ accordingly.

When comparing two offers it is therefore worth looking less at the type number than at the year and emissions standard. The number tells you how heavy and how strong; it says nothing about which generation stands before you.

With gross vehicle weights from 7,300 to 12,090 kg, the TGL spans from EU class N2 (3.5 to 12 t) just into class N3; depending on version, this requires a category C1 or C driving licence, plus a tachograph and driving and rest times in commercial traffic. Early model years of the D08 engines met the Euro 3 standard, later versions the Euro 5 standard with SCR catalysis and AdBlue dosing.

Sources: SpecCodex register, model data: MAN TGL

Technical data

Engine

Cylinders6correct
Displacement6,871 cm³correct

Dimensions and weights

Length9,150 mmcorrect
Width2,400 mmcorrect
Wheelbase4,500 mmcorrect
Unladen weight6,965 kgcorrect
Gross vehicle weight8,600 kgcorrect

Drivetrain and chassis

Wheels4correct

Frequently asked questions

How much does the MAN 8.240 4X2 BL I890 L CHARISMA II weigh?

The unladen weight is 6,965 kg.

What is the gross vehicle weight of the MAN 8.240 4X2 BL I890 L CHARISMA II?

8,600 kg.

What engine does the MAN 8.240 4X2 BL I890 L CHARISMA II have?

6 cylinders, 6,871 cm³ displacement.

What are the dimensions of the MAN 8.240 4X2 BL I890 L CHARISMA II?

9,150 mm × 2,400 mm.

When was the MAN 8.240 4X2 BL I890 L CHARISMA II built?

Production years: 2007.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
