MAN D2676-R02
Built: 2017-2018 · Series: Other models
More machines from model year 2017
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
MAN – other nonroad diesel engines: the collective page of six- to twelve-cylinder ranges outside the named models, model years 2016 to 2026, 217 to 588 kW, consistently Tier 4 Final
MAN carries a second certification series in the EPA register alongside MAN Truck & Bus for the same heavy industrial engines. This page gathers the engines the register could not assign to a named range; model designations such as D2676 or D3876LE carry the typical MAN D code, and the EPA engine-family codes with the digits 09.0, 12.4 and 24.2 reveal the displacement in litres.
Read on 3 more paragraphs
The register lists here 6 versions with 217 to 588 kW rated output at 1,700 to 1,950 rpm, from six- to twelve-cylinders with 115 to 142 mm bore and 145 to 170 mm stroke, torques from 1,550 to 3,754 Nm. Model years run from 2016 as the earliest production start to 2026 as the latest end year; all six versions consistently reach the Tier 4 (Final or Phase-in) emission stage, five fall in the 130 to 560 kW power category, one in the 560 to 900 kW category.
These heavy MAN diesel engines have driven stationary and mobile industrial applications over a long span of model years, from generator sets through pumps to construction machinery, competing with the industrial-engine divisions of Scania, Volvo and Cummins.
On a used purchase, operating hours and the service history of the common-rail injection count, the condition of the turbocharger, the tightness of the charge-air ducting, and on the Tier 4 Final engines the function of the diesel particulate filter and SCR catalyst with AdBlue dosing; spares run through the MAN service network.
Sources: Kennwerte der Modelle MAN (weitere Nonroad-Dieselmotoren), MAN Engines (Hersteller)
Technical data
Engine
| Engine code | LE524correct |
|---|---|
| Engine family | NMNBL12.4OR4; HMNBL12.4OR4; LMNBL12.4OR4; MMNBL12.4OR4; KMNBL12.4OR4; JMNBL12.4OR4correct |
| Engine families | NMNBL12.4OR4; HMNBL12.4OR4; LMNBL12.4OR4; MMNBL12.4OR4; KMNBL12.4OR4; JMNBL12.4OR4correct |
| Fuel | 7-15 ppm Ultra Low Sulfur Dieselcorrect |
| Rated output | 294 kWcorrect |
| Power band | 130<=kW<=560correct |
| Rated speed | 1,950 rpmcorrect |
| Maximum torque | 1,916 N·mcorrect |
| Speed at max. torque | 1,250 rpmcorrect |
| Cylinders | 6correct |
| Cylinder layout | in linecorrect |
| Bore | 126 mmcorrect |
| Stroke | 166 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
| Turbocharger type | Variable Geometry Turbochargercorrect |
| Charge-air cooling | aircorrect |
| Emissions stage | Tier 4 (Final or Phase In)correct |
Origin and approval
| Version | LE524correct |
|---|---|
| Built from | 2017correct |
| Built to | 2022correct |
| Model year from | 2017correct |
| Model year to | 2022correct |
Frequently asked questions
How much power does the MAN D2676-R02 have?
The MAN D2676-R02 delivers 294 kW.
When was the MAN D2676-R02 built?
Production years: 2017-2018.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
