Mahindra & Mahindra Limited VNET352
Built: 2014-2017 · Series: Other models
More machines from model year 2014
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Mahindra & Mahindra Limited – other nonroad diesel engines: the collective page of construction- and farm-machinery engines outside the named models, 18 to 90 kW from three- to four-cylinders, Tier 3 to Tier 4 Final
Mahindra & Mahindra Limited, headquartered in Mumbai and founded in 1945, is one of India's largest conglomerates and one of the highest-selling tractor makers worldwide; its engine division supplies small-displacement diesel engines both for its own compact tractors and construction machinery and for the US market. This page gathers the engines the register could not assign to a named range, from the CE-33 to CE-49 series through DH-45 to DH-65 and HCE343 to HCE374 to HE-39, HE-42, KLU70 and the KSU modelswhile the appended number on several series clearly tracks the rated output.
Read on 3 more paragraphs
The register lists here 64 versions with 18 to 90 kW rated output at 2,100 to 2,800 rpm, from three- to four-cylinders with 88.9 to 98 mm bore and 96 to 132 mm stroke, all with direct injection. Among the emission stages Tier 4 (Final or Phase-in) leads with 52 ahead of Interim Tier 4 with 12 versions; the 37 to 56 kW power category is the largest with 31 versions, maximum torque ranges from 105 to 458 Nm. 63 of the 64 versions are certified for both US certification areas, one solely for states outside California.
Engines of this class drive mini excavators, compact loaders and small farm implements; Mahindra thereby serves both the domestic Indian market and, through its own US subsidiaries, the North American compact construction-machinery segment, where the brand competes chiefly with Kubota and Yanmar.
On a used purchase, operating hours count, the turbocharger (fixed and waste-gate designs depending on the model, some of the smaller engines remain naturally aspirated), the injection pump or injectors, and on Tier 4 Final versions the exhaust aftertreatment; parts supply on the US market is worth clarifying in advance.
Sources: SpecCodex register, model data: Mahindra & Mahindra Limited (weitere Nonroad-Dieselmotoren), Mahindra & Mahindra Limited (manufacturer)
Technical data
Engine
| Engine code | VNET352correct |
|---|---|
| Engine family | HMMLL02.6T52correct |
| Fuel | 7-15 ppm Ultra Low Sulfur Dieselcorrect |
| Rated output | 39 kWcorrect |
| Power band | 37<=kW<56correct |
| Rated speed | 2,300 rpmcorrect |
| Maximum torque | 203 N·mcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 3correct |
| Cylinder layout | in linecorrect |
| Bore | 96 mmcorrect |
| Stroke | 122 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
| Turbocharger type | Fixed Turbochargercorrect |
| Charge-air cooling | aircorrect |
| Emissions stage | Tier 4 (Final or Phase In)correct |
Origin and approval
| Version | VNET352correct |
|---|---|
| Sales region | bothcorrect |
Frequently asked questions
How much power does the Mahindra & Mahindra Limited VNET352 have?
The Mahindra & Mahindra Limited VNET352 delivers 39 kW.
When was the Mahindra & Mahindra Limited VNET352 built?
Production years: 2014-2017.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
