Lts Bzw Doppstadt Systra 750
Series: Systra
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Systra 750: mid-power-class standard tractor, air- and oil-cooled four-cylinder diesel of 2,723 cm³ producing 71 hp at 2,650 rpm, gross weight 2,900 kg
The Systra 750 belongs to the standard tractors of the mid-power class, of the kind used for pulling and transport work in agriculture as well as for municipal tasks.
Read on 3 more paragraphs
The four-cylinder diesel engine of 2,723 cm³ displacement is cooled by air and an oil circuit, so it needs no classic water radiator, and produces 71 hp at 2,650 rpm. Gross weight is 2,900 kg and top speed is 40 km/h, giving a power-to-weight figure of roughly 40.8 kg per hp. At 3,990 mm long, a narrow 1,540 mm wide, 2,260 mm high and with a wheelbase of 2,280 mm, the Systra 750 has a noticeably slim build.
At 40 km/h the Systra 750 reaches the upper limit of licence class L; higher speeds would require class T. The combination of air/oil cooling without a water radiator and the narrow 1,540 mm build makes the machine insensitive to frost and suited to narrow tracks, for instance in forestry or vineyard work.
When buying a tractor with this less common cooling arrangement, it is worth checking the oil cooler and the fan wheel particularly carefully for dirt and damage, since disrupted cooling quickly causes engine damage. The gearbox, clutch, tyres and brakes should also be checked, along with the narrow chassis for stress cracks from work in tight tracks, bearing in mind that spare parts for this less widespread cooling system are only available to a limited extent.
Sources: SpecCodex-Register: Kennwerte des Modells Systra 750
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 71 hp (52 kW)correct |
| Rated speed | 2,650 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 2,723 cm³correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 3,990 mmcorrect |
|---|---|
| Width | 1,540 mmcorrect |
| Height | 2,260 mmcorrect |
| Wheelbase | 2,280 mmcorrect |
| Ground clearance | 310 mmcorrect |
| Unladen weight | 2,900 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 12 vorwärts, 12 rückwärtscorrect |
| Front tyres | 10.5-20 MPTcorrect |
| Rear tyres | 10.5-20 MPTcorrect |
| Top speed | 40 km/hcorrect |
Where this model stands
Power-to-weight ratio: 17.9 kW/t (52 kW / 2.9 t)
Power class: Universal (40–100 hp)
Stronger than 49% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Lts Bzw Doppstadt Systra 750 have?
The Lts Bzw Doppstadt Systra 750 delivers 71 hp.
How much does the Lts Bzw Doppstadt Systra 750 weigh?
The unladen weight is 2,900 kg.
What engine does the Lts Bzw Doppstadt Systra 750 have?
4 cylinders, 2,723 cm³ displacement, Diesel.
How fast does the Lts Bzw Doppstadt Systra 750 go?
Top speed is 40 km/h.
What are the dimensions of the Lts Bzw Doppstadt Systra 750?
3,990 mm × 1,540 mm × 2,260 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 18 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
