Ls Tractors XG4145
Built: 2017 · Series: XR
More machines from model year 2017
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
LS Tractors XG4145: compact tractor with cab from the South Korean brand of LS Mtron, built 2017, water-cooled three-cylinder diesel of 1,879 cm³ producing 45 hp at 2,600 rpm
LS Tractors is the farm-machinery brand of the South Korean company LS Mtron, part of the LS Group, which builds compact tractors in various equipment levels for the world market.
Read on 3 more paragraphs
The XG4145, built in 2017, is powered by a water-cooled three-cylinder diesel engine of 1,879 cm³ displacement, producing 45 hp, equivalent to 34 kW, at 2,600 rpm. The three-point hitch lifts up to 1,250 kg. With the cab fitted, the machine measures 2,282 mm in height and weighs 1,986 kg, giving a power-to-weight figure of roughly 44.1 kg per hp. Length is 3,413 mm, width 1,611 mm and wheelbase 1,858 mm.
The enclosed cab sets the XG4145 apart from open compact tractors and provides weather protection and greater comfort during longer jobs, such as winter road service or all-day grounds maintenance. The 1,250 kg lift capacity is enough for medium implements such as a sweeper, snow blade or rotary harrow.
When buying a used compact tractor with a cab, besides the general checks of the hydraulics, engine and gearbox, it is worth taking a close look at the cab and window seals and testing the heater or air conditioning, since leaks are common there on older examples. Tyres, brakes, the front axle, and the availability of a dealer for spare parts for this Korean import brand also belong on the checklist, together with the engine hour meter.
Sources: SpecCodex-Register: Kennwerte des Modells XG4145
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 45 hp (34 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 1,879 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,413 mmcorrect |
|---|---|
| Width | 1,611 mmcorrect |
| Height | 2,282 mm (with cab)correct |
| Wheelbase | 1,858 mmcorrect |
| Unladen weight | 1,986 kg (with cab)correct |
Drivetrain and chassis
| Front tyres | 9.5-16correct |
|---|---|
| Rear tyres | 13.6-24correct |
Working data
| Lifting capacity | 1,250 kgcorrect |
|---|
Where this model stands
Power-to-weight ratio: 17.1 kW/t (34 kW / 2 t)
Power class: Universal (40–100 hp)
Stronger than 30% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Ls Tractors XG4145 have?
The Ls Tractors XG4145 delivers 45 hp.
How much does the Ls Tractors XG4145 weigh?
The unladen weight is 1,986 kg.
What engine does the Ls Tractors XG4145 have?
3 cylinders, 1,879 cm³ displacement, Diesel.
How much does the rear linkage of the Ls Tractors XG4145 lift?
The rear linkage lifts 1,250 kg.
What are the dimensions of the Ls Tractors XG4145?
3,413 mm × 1,611 mm × 2,282 mm.
When was the Ls Tractors XG4145 built?
Production years: 2017.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
