Ls Tractors XG3140
Built: 2017 · Series: XG
More machines from model year 2017
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
LS Tractors XG3140: narrow compact tractor from the South Korean brand of LS Mtron, built 2017, water-cooled three-cylinder diesel of 1,879 cm³ producing 40 hp at 2,600 rpm
LS Tractors is the farm-machinery brand of the South Korean company LS Mtron, part of the LS Group, which builds narrower compact tractors for the world market alongside larger models.
Read on 3 more paragraphs
The XG3140, built in 2017, is powered by a water-cooled three-cylinder diesel engine of 1,879 cm³ displacement, producing 40 hp, equivalent to 30 kW, at 2,600 rpm. Gross weight is 1,329 kg, giving a power-to-weight figure of roughly 33.2 kg per hp. The three-point hitch lifts up to 820 kg. At 3,322 mm long, just 1,374 mm wide, 2,341 mm high and with a wheelbase of 1,754 mm, the XG3140 has a noticeably narrow build.
The narrow 1,374 mm width makes the XG3140 suited to work in tight crop rows such as orchards, berry plantations or vineyards, where wider standard tractors cannot pass. The 820 kg lift capacity is enough for light implements matching such a narrow design, such as a mower or a small rotary tiller.
When buying such a narrow compact tractor it is worth checking the fenders and bodywork, as these often show contact damage from working in tight rows. The hydraulics and their connections, tyres and brakes should also be checked, along with engine hours relative to outward condition, the front axle and steering linkage, and the availability of a dealer for spare parts for this Korean import brand.
Sources: SpecCodex-Register: Kennwerte des Modells XG3140
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 40 hp (30 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 1,879 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,322 mmcorrect |
|---|---|
| Width | 1,374 mmcorrect |
| Height | 2,341 mmcorrect |
| Wheelbase | 1,754 mmcorrect |
| Unladen weight | 1,329 kgcorrect |
Drivetrain and chassis
| Front tyres | 7-14correct |
|---|---|
| Rear tyres | 11.2-24correct |
Working data
| Lifting capacity | 820 kgcorrect |
|---|
Where this model stands
Power-to-weight ratio: 22.6 kW/t (30 kW / 1.3 t)
Power class: Compact (< 40 hp)
Stronger than 26% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Ls Tractors XG3140 have?
The Ls Tractors XG3140 delivers 40 hp.
How much does the Ls Tractors XG3140 weigh?
The unladen weight is 1,329 kg.
What engine does the Ls Tractors XG3140 have?
3 cylinders, 1,879 cm³ displacement, Diesel.
How much does the rear linkage of the Ls Tractors XG3140 lift?
The rear linkage lifts 820 kg.
What are the dimensions of the Ls Tractors XG3140?
3,322 mm × 1,374 mm × 2,341 mm.
When was the Ls Tractors XG3140 built?
Production years: 2017.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
