LS XR5065
Built: 2013-2013 · Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The LS XR5065 rolled off the line in 2013 as a tractor. The four-cylinder engine produces 48 kW. Rated speed is 2,600 rpm.
It combines a Power shuttle gearbox with MFWD.
It runs on diesel; the engine is water-cooled. Within the range, rated power spans from 17 to 290 kW; with 48 kW, the XR5065 sits in the upper third. Directly alongside are the N60 NEO with 45 kW below and the LS804-1 with 60 kW above.
Technical data
Engine
| Engine make | Shibauracorrect |
|---|---|
| Engine model | N4LDI-TAcorrect |
| Fuel | dieselcorrect |
| Power | 65 hp (48 kW)correct |
| Rated speed | 2.6 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 135.2 cu incorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 140 in (3 556 mm)correct |
|---|---|
| Width | 67.5 in (1714,5 mm)correct |
| Height | 100.4 in (2550,2 mm)correct |
| Wheelbase | 80.6 in (2047,2 mm)correct |
| Unladen weight | 4,667 lbs (2116,9 kg)correct |
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|---|
| Gearbox | Power shuttlecorrect |
| Forward gears | 16correct |
| Reverse gears | 16correct |
Working data
| Lifting capacity | 4,079 lbs (1850,2 kg)correct |
|---|---|
| Fuel tank capacity | 15.6 galcorrect |
| PTO speed | 540correct |
| Linkage category | Cat IIcorrect |
Origin and approval
| Plant | South Koreacorrect |
|---|
Frequently asked questions
How much power does the LS XR5065 have?
The LS XR5065 delivers 65 hp.
What engine does the LS XR5065 have?
4 cylinders, Diesel.
When was the LS XR5065 built?
Production years: 2013.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
