Lindner 1750 N / A
Built: 1991–1996 · Series: Neue 1000 er - Reihe
More machines from model year 1991
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Lindner New 1000 series (Kundl, Tyrol) – compact tractors with N for two-wheel drive and A for four-wheel drive: 1450 to 1750 Turbo, three- and four-cylinder diesels of 2.5 to 4.0 litres, 52 to 72 hp, 2.1 to 2.9 t
The New 1000 series is the upgraded reissue of Lindner's classic 1000 range, built at the Kundl works in Tyrol, where the company founded in 1948 by Hermann Lindner has made compact and mountain tractors ever since. The type logic: the number from 1450 to 1750 orders the power class in ascending order, N stands for two-wheel drive, A for four-wheel drive, with the 1600 Turbo the turbocharged version at the top of the range. The engines are three- and four-cylinder diesels of 2.5 to 4.0 litres, the design following Lindner's focus on agile tractors suited to steep slopes with a narrow track and low centre of gravity.
Read on 3 more paragraphs
The register lists 6 versions with 52 to 72 hp from three- and four-cylinder diesels of 2,502 to 4,000 cm³ at 2,200 to 2,400 rpm, unladen weights from 2,056 to 2,870 kg, lengths from 3,450 to 3,745 mm, widths from 1,660 to 1,893 mm and heights from 2,235 to 2,550 mm.
The New 1000 series was the tractor of Tyrolean and Bavarian mountain and grassland farms, where Lindner ranks alongside Steyr and Fendt's compact models as an established make; the narrow build and the four-wheel-drive version also made the range attractive to vineyards and orchards on steep ground.
On used tractors, engine and injection pump, clutch and gearbox, the four-wheel-drive clutch on A models, hydraulics and linkage, brakes and sheet metal and frame count, more heavily strained in mountain work by slurry and damp; parts run through Lindner authorised workshops.
Sources: SpecCodex register, model data: Lindner Neue 1000er-Reihe, Lindner Traktorenwerk (Hersteller, Kundl)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 72 hpcorrect |
| Power | 72 hpcorrect |
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,000 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,745 mmcorrect |
|---|---|
| Width | 1,893 mmcorrect |
| Height | 2,480 mmcorrect |
| Wheelbase | 2,155 mmcorrect |
| Unladen weight | 2,870 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 16V / 8Rcorrect |
| Forward gears | 16correct |
| Reverse gears | 8correct |
| Front tyres | 9, 00-16 ( A, Typ 1: 10, 5-20 )correct |
| Rear tyres | 16, 9-30 ( A, Typ 1: 14, 9 R-30 )correct |
| Top speed | 35 km/hcorrect |
Origin and approval
| Units built | 724correct |
|---|
Where this model stands
Power-to-weight ratio: 18.4 kW/t (53 kW / 2.9 t)
Power class: Universal (40–100 hp)
Stronger than 50% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Lindner 1750 N / A have?
The Lindner 1750 N / A delivers 72 hp.
How much does the Lindner 1750 N / A weigh?
The unladen weight is 2,870 kg.
What engine does the Lindner 1750 N / A have?
4 cylinders, 4,000 cm³ displacement, Diesel.
How fast does the Lindner 1750 N / A go?
Top speed is 35 km/h.
What are the dimensions of the Lindner 1750 N / A?
3,745 mm × 1,893 mm × 2,480 mm.
When was the Lindner 1750 N / A built?
Production years: 1991–1996.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
