Lindner BF 620 SN / SA

Built: 1975–1985 · Series: 20 er - Reihe

More machines from model year 1975

Source: https://www.technikboerse.at/gebraucht/traktor-357/lindner-7

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the BF 620 SN / SA, Lindner offers a model from the 20er - Reihe series. Production: 1975–1985. The engine delivers 62 hp, has 4 cylinders, with a displacement of 3,863 cm³. Rated speed is 2,250 rpm. The machine is 3,500 mm long, 1,730 mm wide and 2,290 mm high. The unladen weight is 2,010 kg. The wheelbase measures 2,050 mm. Transmission: 8V / 4R. The engine is water-cooled. Tyres: front 7,50-16 ( SA: 10,6-18 ), rear 14,9/13-28. The fuel is diesel. The bore measures 98.4 mm. The stroke is 127 mm. Construction: unit construction (no separate frame). The gearbox offers 8 forward gears. There are also 4 reverse gears. Injection pressure is 170 bar. Around 1453 units were built. Rated output across the Lindner range ranges from 8 to 116 hp; the BF 620 SN / SA sits in the middle of that range with 62 hp. Its immediate neighbours are the BF 550 SN / SA below it with 58 hp and the 1065 N/A above it with 65 hp. Rated output across the Lindner range ranges from 14 to 116 hp; here the BF 620 SN / SA sits in the middle of that range with 62 hp. 48 Lindner models across 18 series are on record.

Lindner 20 series – mountain tractors from Kundl in the Tyrol: BF 420 and BF 620, each in two drive versions, three- and four-cylinder engines, 42 to 62 hp

The 20 series from Lindner of Kundl in the Tyrol likewise represents a compact mountain tractor, independent of the marque's 1000 series. The BF 420 SN/SA and BF 620 SN/SA models, with three- and four-cylinder engines, cover a wider power range than the 1000 series and were likewise offered in two drive versions each.

Read on 3 more paragraphs

The register lists 2 versions here with 42 to 62 hp from three- and four-cylinder diesel engines of 2,502 to 3,863 cm³ displacement, at 2,250 to 2,400 revolutions per minute. Kerb weights range from 1,720 to 2,010 kg, lengths from 3,250 to 3,500 mm, widths from 1,600 to 1,730 mm and heights from 2,130 to 2,290 mm.

With the smaller BF 420 and the stronger BF 620, Lindner already covered a range from light slope tractor to a more powerful all-rounder within the 20 series itself, letting farms in the alpine valleys choose the machine to match holding and field size without switching brand.

When buying used, compression and cooling should be checked separately across the different engine sizes, since the stronger four-cylinder is under greater thermal load in continuous slope work. Steering, front-axle bearings and the hydraulics for front and rear implements show wear first under intensive use; spare parts are supplied by the manufacturer and by workshops in the Tyrol specialising in Lindner tractors.

Sources: SpecCodex register, model data: Lindner 20er-Reihe, Lindner Traktorenwerk (manufacturer)

Technical data

Engine

Fuel	dieselcorrect
Power	62 hpcorrect
Power	62 hpcorrect
Rated speed	2,250 rpmcorrect
Cylinders	4correct
Displacement	3,863 cm³correct
Bore	98.4 mmcorrect
Stroke	127 mmcorrect
Injection pressure	170 barcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	3,500 mmcorrect
Width	1,730 mmcorrect
Height	2,290 mmcorrect
Wheelbase	2,050 mmcorrect
Unladen weight	2,010 kgcorrect

Drivetrain and chassis

Drive	rear-wheel drivecorrect
Gearbox	8V / 4Rcorrect
Forward gears	8correct
Reverse gears	4correct
Front tyres	7, 50-16 ( SA: 10, 6-18 )correct
Rear tyres	14, 9/13-28correct

Origin and approval

Construction	unit construction (no separate frame)correct
Units built	1,453correct

Where this model stands

Power-to-weight ratio: 22.7 kW/t (46 kW / 2 t)

Power class: Universal (40–100 hp)

Stronger than 43% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Lindner BF 620 SN / SA have?

The Lindner BF 620 SN / SA delivers 62 hp.

How much does the Lindner BF 620 SN / SA weigh?

The unladen weight is 2,010 kg.

What engine does the Lindner BF 620 SN / SA have?

4 cylinders, 3,863 cm³ displacement, Diesel.

What are the dimensions of the Lindner BF 620 SN / SA?

3,500 mm × 1,730 mm × 2,290 mm.

When was the Lindner BF 620 SN / SA built?

Production years: 1975–1985.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
