Liebherr R920 COMPACT LITRONIC – specifications

Series: Liebherr Hydraulic Excavator

The Liebherr R920 COMPACT LITRONIC is a model in the Liebherr Hydraulic Excavator series. The engine has 4 cylinders, with a displacement of 4,501.5 cm³. Rated speed is 1,800 rpm. The unladen weight is 48,280 kg. The wheelbase measures 3,383.3 mm. Ground clearance is 518.2 mm. Working pressure is 350 bar. The engine fitted is the D924 A7-04. The Liebherr Hydraulic Excavator series covers 43 models. Unladen weight within it ranges from 15,300 to 659,000 kg; the R920 COMPACT LITRONIC sits at the bottom of that range with 48,280 kg. Its immediate neighbours are the R946 LITRONIC below it with 47,799.6 kg and the R954C above it with 49,201.2 kg. 548 Liebherr models across 45 series are on record.

Build year not documented · Data origin: Directory data · sources

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

Liebherr R-series: crawler excavator codes between size class and Litronic generation

The "R" in Liebherr's excavator range stands for crawler (Raupe) and separates the line from the wheeled "A" models. The number that follows marks the size class: across the 41 R-series models recorded in SpecCodex, operating weight spans 15,300 to 659,000 kg — from compact excavators in the R-31x class up to mining-scale machines weighing in the hundreds of tonnes.

Read on 3 more paragraphs

The "Litronic" suffix denotes Liebherr's electronically controlled hydraulic system, standard on nearly all R models since the 1980s. Trailing letters (A, B, C…) instead mark successive revision generations of the same model, usually tied to new emissions stages and engines.

For the machines recorded in the database, engine output ranges from 62 to 949 kW, displacement from 3,000 to 65,000 cm³, and cylinder count from 4 to 16 — a span running from compact building-site excavators up to the large engines fitted to mining machines.

When buying used, the generation letter after the number is the best clue to emissions stage and control generation fitted; also check the undercarriage and arm bushings, and cross-check the hour meter against the service book. Models such as R312, R904C, R912 and R996 illustrate the range from compact excavator to large-scale machine.

Sources: SpecCodex register, model data: Liebherr Hydraulic Excavator, – R 928 Litronic, Liebherr, – Erklärung Typenbezeichnungen Liebherr-Bagger, Bauforum24

Technical data

Engine

Engine modelD924 A7-04correct
Rated speed1,800 rpmcorrect
Cylinders4correct
Displacement4,501.5 cm³correct
AspirationTurbo-charged and after-coolerreduced emissionscorrect

Dimensions and weights

Wheelbase3,383.3 mmcorrect
Ground clearance518.2 mmcorrect
Unladen weight48,280 kgcorrect

Working data

Hydraulic pressure350 barcorrect

Other data

Cab height2,468.9 mmcorrect

Frequently asked questions

How much does the Liebherr R920 COMPACT LITRONIC weigh?

The unladen weight of the Liebherr R920 COMPACT LITRONIC is 48,280 kg.

What engine does the Liebherr R920 COMPACT LITRONIC have?

The Liebherr R920 COMPACT LITRONIC has 4 cylinders and 4,501.5 cm³ displacement.

Used listings – figures from public listings

Between August and November 2026, speccodex recorded 6 public used-machine listings for Liebherr R920 COMPACT LITRONIC on 2 platforms. Asking prices ranged from €79,900 to €212,000 (median €175,000), years of manufacture between 2018 and 2023.

Offered mainly in Germany (67%), France (17%) and Finland (17%); shares refer to listings that state a location.

Asking prices are sellers' demands, not achieved sale prices. Basis: public listings, recorded and analysed by speccodex. As of: 18 Nov 2026. Sellers usually do not state whether prices are net or gross.

More machines with this engine (D924 A7-04, 2)

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
