Liebherr PR766 LITRONIC Crawler

Series: Other models

Source: https://www.liebherr.com/en-us/earthmoving/products/crawler-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Liebherr Crawler Tractor series from Liebherr includes the PR766 LITRONIC. The engine delivers 489.5 hp (310.1 kW), with a displacement of 16,200.3 cm³. Rated speed is 1,600 rpm. The unladen weight is 54,187 kg. Ground clearance is 682.8 mm. The tank holds 840.4 litres. The pump delivers 352 l/min. The cooling system holds 90.1 litres. The oil fill is 65.1 litres. The electrical system runs on 24 V. The engine fitted is the D 9508 A7-04 Emission regulations . EPA/CARB Tier 4f. The Liebherr Crawler Tractor series covers 25 models. Rated output within it ranges from 133.8 to 688 hp; the PR766 LITRONIC sits in the upper part of that range with 489.5 hp. Its immediate neighbours are the PR764 below it with 427.9 hp and the PR776 LITRONIC above it with 688 hp. 480 Liebherr models across 20 series are on record. The model is listed under Mining equipment. 15 verified figures from 1 source are on file.

Technical data

Engine

Engine modelD 9508 A7-04 Emission regulations, EPA/CARB Tier 4fcorrect
Power489.5 hp (310.1 kW)correct
Rated speed1,600 rpmcorrect
Displacement16,200.3 cm³correct
AspirationTurbochangedcorrect
Coolant capacity90.1 lcorrect
Engine oil capacity65.1 lcorrect

Dimensions and weights

Ground clearance682.8correct
Unladen weight54,187 kgcorrect

Drivetrain and chassis

Gearbox typecontinuously variable transmission hydrostatic transmission travel drive, independent drive for each trackcorrect
System voltage24 Vcorrect

Working data

Pump flow352 l/mincorrect
Fuel tank capacity840.4 lcorrect

Other data

Height3,971.5correct

Where this model stands

Power-to-weight ratio: 5.7 kW/t (310 kW / 54.2 t)

Stronger than 82% of the mining equipment in the register — out of 945 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Liebherr PR766 LITRONIC have?

The Liebherr PR766 LITRONIC delivers 490 hp.

How much does the Liebherr PR766 LITRONIC weigh?

The unladen weight is 54,187 kg.

What engine does the Liebherr PR766 LITRONIC have?

16,200 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 15 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
