Liebherr L566

Series: Liebherr Wheel Loader

Source: https://www.liebherr.com/de-de/p/241925-3838636

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Liebherr L566 is a model in the Liebherr Wheel Loader series. The engine delivers 258.5 hp (190.2 kW), has 4 cylinders, with a displacement of 10,520.5 cm³. Rated speed is 1,300 rpm. The unladen weight is 23,149.1 kg. The wheelbase measures 3,810 mm. Ground clearance is 579.1 mm. The tank holds 401.3 litres. The gearbox has 3 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,300 rpm. The pump delivers 291.5 l/min. The hydraulic tank holds 265 litres. The cooling system holds 51.9 litres. The engine fitted is the D936 A7. Tyre size: 23,5R25 L3. The Liebherr Wheel Loader series covers 37 models. Rated output within it ranges from 99.4 to 357.9 hp; the L566 sits in the upper part of that range with 258.5 hp. Its immediate neighbours are the L566 2plus2 below it with 258.3 hp and the L574 2plus2 above it with 268.7 hp. 480 Liebherr models across 20 series are on record. The model is listed under Wheel loaders. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine modelD936 A7correct
Power258.5 hp (190.2 kW)correct
Rated speed1,300 rpmcorrect
Speed at max. torque1,300 rpmcorrect
Cylinders4correct
Displacement10,520.5 cm³correct
AspirationWater-cooled with exhaust turbo charging, externally cooled exhaust gas recirculcorrect
Coolant capacity51.9 lcorrect

Dimensions and weights

Wheelbase3,810correct
Ground clearance579.1correct
Unladen weight23,149.1 kgcorrect

Drivetrain and chassis

Forward gears3correct
Reverse gears3correct
Tyre size23.5R25 L3correct

Working data

Pump flow291.5 l/mincorrect
Hydraulic oil capacity265 lcorrect
Fuel tank capacity401.3 lcorrect

Other data

Height3,627.1correct

Where this model stands

Power-to-weight ratio: 8.2 kW/t (190 kW / 23.1 t)

Stronger than 83% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Liebherr L566 have?

The Liebherr L566 delivers 258 hp.

How much does the Liebherr L566 weigh?

The unladen weight is 23,149 kg.

What engine does the Liebherr L566 have?

4 cylinders, 10,520 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
