Liebherr A924C

Series: Liebherr Material Handler

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Liebherr A924C is a model in the Liebherr Material Handler series. The engine delivers 186.6 hp (137.2 kW), with a displacement of 7,000.6 cm³. The wheelbase measures 2,801.1 mm. Ground clearance is 356.6 mm. Top speed is 20.1 km/h. The tank holds 400.1 litres. The hydraulic tank holds 430 litres. The electrical system runs on 24 V. The engine fitted is the D 934 L. Tyre size: 11,00-20. The Liebherr Material Handler series covers 51 models. Rated output within it ranges from 136.9 to 543.4 hp; the A924C sits at the bottom of that range with 186.6 hp. Its immediate neighbours are the LH26M INDUSTRY LITRONIC below it with 156.1 hp and the LH30C INDUSTRY LITRONIC above it with 190.6 hp. 480 Liebherr models across 20 series are on record. The model is listed under Excavators & compaction. 12 verified figures from 1 source are on file.

Technical data

Engine

Engine modelD 934 Lcorrect
Power186.6 hp (137.2 kW)correct
Displacement7,000.6 cm³correct
Aspirationturbo-charged and after-cooled reduced emissionscorrect

Dimensions and weights

Wheelbase2,801.1correct
Ground clearance356.6correct

Drivetrain and chassis

Tyre size11.00-20correct
Top speed20.1 km/hcorrect
System voltage24 Vcorrect

Working data

Hydraulic oil capacity430 lcorrect
Fuel tank capacity400.1 lcorrect

Frequently asked questions

How much power does the Liebherr A924C have?

The Liebherr A924C delivers 187 hp.

What engine does the Liebherr A924C have?

7,001 cm³ displacement.

How fast does the Liebherr A924C go?

Top speed is 20.1 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
