Lamborghini R-240 (DT)
Built: 1970–1973 · Series: Zweite R-Baureihe
More machines from model year 1970
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Lamborghini R series: compact agricultural tractors from Cento/Pieve di Cento, from the R-240 (DT) to the R-360 (DT), 28.7 to 39 kW from two- and three-cylinder diesel engines
Lamborghini Trattori was founded in 1948 by Ferruccio Lamborghini in Cento and has been part of the SAME group since 1972, which builds the tractors at the Pieve di Cento plant. This page collects a further R series from the marque, from the R-240 (DT) to the R-360 (DT); the leading number gives the approximate size class, and DT in Italian tractor typology stands for Doppia Trazione, meaning four-wheel drive.
Read on 3 more paragraphs
The register lists 2 versions from 28.7 to 39 kW from two- and three-cylinder diesel engines of 1,885 to 2,827 cm³ displacement at 2,200 to 2,400 rpm. Kerb weights range from 1,700 to 1,900 kg, lengths from 2,860 to 2,990 mm, widths from 1,650 to 1,690 mm and heights from 1,260 to 1,290 mm.
Tractors of this power and weight class cover the small and compact segment at Lamborghini, suited to smaller farms, special crops and yard work; the low build height eases use under trees and inside greenhouses, while the two- and three-cylinder engines keep fuel consumption modest for light tillage and yard transport.
When buying a used example, check operating hours and the service history of engine and injection pump, the condition of clutch, gearbox and four-wheel drive, the tightness of the hydraulics, and corrosion on sheet-metal parts and wings; since the engineering is largely shared with Same and Deutz-Fahr, spare-parts supply through the SDF dealer network is comparatively good.
Sources: SpecCodex register, model data: Lamborghini R-Baureihe, Lamborghini Trattori (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 39 hp (28.7 kW)correct |
| Rated speed | 2,400 rpmcorrect |
| Cylinders | 2correct |
| Displacement | 1,885 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 120 mmcorrect |
| Injection pressure | 180 barcorrect |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 2,860 mmcorrect |
|---|---|
| Width | 1,650 mmcorrect |
| Height | 1,260 mmcorrect |
| Wheelbase | 1,790 mmcorrect |
| Ground clearance | 420 mmcorrect |
| Unladen weight | 1,700 kgcorrect |
Drivetrain and chassis
| Drive | rear- and four-wheel drivecorrect |
|---|---|
| Gearbox | 12 V/3 Rcorrect |
| Forward gears | 12correct |
| Reverse gears | 3correct |
| Front tyres | 5.00-16 ASF (DT: 7.50-20 AS)correct |
| Rear tyres | 11.2-24 AScorrect |
| Top speed | 25 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|---|
| Units built | 327 (DT: 285)correct |
Other data
| Linkage category | Cat Icorrect |
|---|
Where this model stands
Power-to-weight ratio: 16.9 kW/t (29 kW / 1.7 t)
Power class: Compact (< 40 hp)
Stronger than 24% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Lamborghini R-240 (DT) have?
The Lamborghini R-240 (DT) delivers 39 hp.
How much does the Lamborghini R-240 (DT) weigh?
The unladen weight is 1,700 kg.
What engine does the Lamborghini R-240 (DT) have?
2 cylinders, 1,885 cm³ displacement, Diesel.
How fast does the Lamborghini R-240 (DT) go?
Top speed is 25 km/h.
What are the dimensions of the Lamborghini R-240 (DT)?
2,860 mm × 1,650 mm × 1,260 mm.
When was the Lamborghini R-240 (DT) built?
Production years: 1970–1973.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
