Kukje Machinery A2000N3

Built: 2017-2022 · Series: Other models

More machines from model year 2017

Source: kubota.com

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The A2000N3 comes from Kukje Machinery. Production: 2017-2022. The fuel is 7-15 ppm Ultra Low Sulfur Diesel. The rated output is 29 kW. The engine is naturally aspirated. The engine meets emissions stage Tier 4 (Final or Phase In). Fuel reaches the combustion chamber through indirect injection. It is a four-stroke diesel engine. The cylinders are arranged in line. Rated output across the Kukje Machinery range ranges from 13 to 64 kW; the A2000N3 sits in the lower part of that range with 29 kW. Its immediate neighbours are the A1700N1 below it with 28 kW and the A1700T1 above it with 30 kW. 41 Kukje Machinery models across 2 series are on record.

Kukje Machinery – further nonroad diesel engines: the collective page for the A1100 to A2300 series outside the named models, three- and four-cylinder units from 13 to 64 kW, model years 2011 to 2022

Kukje Machinery is a South Korean maker of small diesel engines. This page gathers 32 variants of the A1100, A1500, A1700, A2000 and A2300 series that the register could not assign to any named main series. Within these series, several generations run in parallel, identifiable by the suffixes “Gen”, “Gen1” and “Gen2”, along with application variants carrying the suffixes N1 to N6 and T1 to T4.

Read on 3 more paragraphs

The register lists 32 variants here rated from 13 to 64 kW at 1,500 to 2,800 rpm, three- to four-cylinder engines with a bore of 78 to 98 mm and a stroke of 82 to 113 mm. Maximum torque ranges from 65 to 336.7 Nm at 1,500 to 2,200 rpm, model years from 2011 to 2022. Among emission tiers, Tier 4 (Final or Phase-in) leads narrowly with 16 variants ahead of Interim Tier 4 with 15 and Tier 3 with one; the 19–37 kW power category is the most common with 19 variants, followed by 37–56 kW and 8–19 kW with 6 each. 29 of the 32 engines are certified for sale in all US states, 3 only outside California.

Engines of this class drive mini-excavators, compact loaders and small generator sets; the parallel line-up of several generations and application variants within the same series designation points to a continuously maintained base design, adapted for different equipment makers over the years.

When buying used, the only 11 turbocharged variants call for a check of boost pressure and turbocharger condition, while the mostly indirect-injection engines additionally need glow plugs and cold-start behaviour checked; oil consumption and the tightness of crankshaft seals also matter. Since model years reach back to 2011, running hours are worth checking too.

Sources: SpecCodex register, model data: Kukje Machinery (weitere Nonroad-Dieselmotoren)

Technical data

Engine

Engine codeA2000N3correct
Engine familyNKMCL2.29A48correct
Engine familiesNKMCL2.29A48; HKMCL2.09A43; LKMCL2.29A48; JKMCL2.09A43; MKMCL2.29A48; KKMCL2.29A48correct
Fuel7-15 ppm Ultra Low Sulfur Dieselcorrect
Rated output29 kWcorrect
Power band19<=kW<37correct
Rated speed2,600 rpmcorrect
Maximum torque122.7 N·mcorrect
Speed at max. torque1,500 rpmcorrect
Cylinders4correct
Cylinder layoutin linecorrect
Bore84 mmcorrect
Stroke94 mmcorrect
Operating cyclefour-stroke dieselcorrect
Injectionindirect injectioncorrect
Aspirationnaturally aspiratedcorrect
Emissions stageTier 4 (Final or Phase In)correct

Origin and approval

VersionA2000N3correct
Built from2017correct
Built to2022correct
Model year from2017correct
Model year to2022correct
Sales regionbothcorrect

Frequently asked questions

How much power does the Kukje Machinery A2000N3 have?

The Kukje Machinery A2000N3 delivers 29 kW.

When was the Kukje Machinery A2000N3 built?

Production years: 2017-2022.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
