Kubota L4701-2WD 2WD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
As a tractor, the Kubota L4701-2WD belongs to the Kubota 2WD Tractor series. Under the bonnet works a four-cylinder engine displacing 2.4 litres, producing 48 hp (33.4 kW).
It will not go faster than 24 km/h — a working pace, not a travelling one. Dimensions are 3.12 m by 1.59 m. Unladen, it tips the scales at 1,460 kg.
Within the range, rated power spans from 25.1 to 93.4 hp; with 48 hp, the L4701-2WD sits in the mid-field. Directly alongside are the L3901-2WD with 38 hp below and the M5660SUH with 58.7 hp above.
Technical data
Engine
| Engine make | KUBOTAcorrect |
|---|---|
| Engine model | V2403-CR-E4correct |
| Power | 48 hp (33.4 kW)correct |
| Torque | 146.3correct |
| Cylinders | 4correct |
| Displacement | 2,433.5 cm³correct |
| Coolant capacity | 6.8 lcorrect |
Dimensions and weights
| Length | 3,120.1correct |
|---|---|
| Width | 1,588correct |
| Wheelbase | 1,850.1correct |
| Ground clearance | 385.1correct |
| Unladen weight | 1,460 kgcorrect |
Drivetrain and chassis
| Gearbox type | manual gearbox Transmission - constant-mesh gearbox with synchromesh gearbox shuttlecorrect |
|---|---|
| Forward gears | 8correct |
| Reverse gears | 8correct |
| Top speed | 24.1 km/hcorrect |
| System voltage | 12 Vcorrect |
Working data
| Pump flow | 29.5 l/mincorrect |
|---|---|
| Fuel tank capacity | 51.1 lcorrect |
Where this model stands
Power-to-weight ratio: 22.9 kW/t (33 kW / 1.5 t)
Power class: Universal (40–100 hp)
Stronger than 31% of the tractors in the register — out of 15,240 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Kubota L4701-2WD have?
The Kubota L4701-2WD delivers 48 hp.
How much does the Kubota L4701-2WD weigh?
The unladen weight is 1,460 kg.
What engine does the Kubota L4701-2WD have?
4 cylinders, 2,434 cm³ displacement.
How fast does the Kubota L4701-2WD go?
Top speed is 24.1 km/h.
What are the dimensions of the Kubota L4701-2WD?
3,120 mm × 1,588 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
