Kubota L3901-2WD 2WD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
As a tractor, the Kubota L3901-2WD belongs to the Kubota 2WD Tractor series. Under the bonnet works a three-cylinder engine displacing 1.8 litres, producing 38 hp (27.1 kW).
At 21 km/h, that is as fast as it goes. Dimensions are 2.81 m by 1.40 m. Empty, it weighs 1,175 kg.
Within the range, rated power spans from 25.1 to 93.4 hp; with 38 hp, the L3901-2WD sits in the lower third. Directly alongside are the L3301-2WD with 33.5 hp below and the L4701-2WD with 48 hp above.
Technical data
Engine
| Engine make | KUBOTAcorrect |
|---|---|
| Engine model | D1803-CR-E4correct |
| Power | 38 hp (27.1 kW)correct |
| Torque | 115.9correct |
| Cylinders | 3correct |
| Displacement | 1,825.5 cm³correct |
| Coolant capacity | 6.1 lcorrect |
Dimensions and weights
| Length | 2,810correct |
|---|---|
| Width | 1,402.1correct |
| Wheelbase | 1,612.4correct |
| Ground clearance | 345.2correct |
| Unladen weight | 1,175 kgcorrect |
Drivetrain and chassis
| Gearbox type | manual gearbox Transmission - Gear shift with synchromesh gearbox shuttlecorrect |
|---|---|
| Forward gears | 8correct |
| Reverse gears | 8correct |
| Top speed | 21.2 km/hcorrect |
| Turning radius | 2,410 mmcorrect |
Working data
| Lifting capacity | 650 kgcorrect |
|---|---|
| Pump flow | 23.8 l/mincorrect |
| Fuel tank capacity | 42 lcorrect |
Other data
| PTO output | 32 hpcorrect |
|---|---|
| System voltage | 12 Vcorrect |
More machines with this engine (KUBOTA D1803-CR-E4, 5)
Where this model stands
Power-to-weight ratio: 23.1 kW/t (27 kW / 1.2 t)
Power class: Compact (< 40 hp)
Stronger than 24% of the tractors in the register — out of 15,030 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Kubota L3901-2WD have?
The Kubota L3901-2WD delivers 38 hp.
How much does the Kubota L3901-2WD weigh?
The unladen weight is 1,175 kg.
What engine does the Kubota L3901-2WD have?
3 cylinders, 1,826 cm³ displacement.
How fast does the Kubota L3901-2WD go?
Top speed is 21.2 km/h.
What is the PTO output of the Kubota L3901-2WD?
PTO output is 32 hp.
How much does the rear linkage of the Kubota L3901-2WD lift?
The rear linkage lifts 650 kg.
What are the dimensions of the Kubota L3901-2WD?
2,810 mm × 1,402 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
