Kubota L2501-4WD 4WD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
As a tractor, the Kubota L2501-4WD belongs to the Kubota 4WD Tractor series. 25 hp (17.8 kW) is what the three-cylinder engine gets out of 1.6 litres.
It will not go faster than 17 km/h — a working pace, not a travelling one. It measures 2.81 m in length. Unladen, it tips the scales at 1,180 kg.
Within the range, rated power spans from 18.2 to 116 hp; with 25.1 hp, the L2501-4WD sits at the bottom end. Directly alongside are the B7610HSD with 24.3 hp below and the BX2660 with 25.9 hp above.
Technical data
Engine
| Engine make | KUBOTAcorrect |
|---|---|
| Engine model | D1703-M-DI-E4correct |
| Power | 25.1 hp (17.8 kW)correct |
| Torque | 95.3correct |
| Cylinders | 3correct |
| Displacement | 1,646.9 cm³correct |
| Coolant capacity | 6.1 lcorrect |
Dimensions and weights
| Length | 2,810correct |
|---|---|
| Wheelbase | 1,610.1correct |
| Ground clearance | 340.1correct |
| Unladen weight | 1,180 kgcorrect |
Drivetrain and chassis
| Gearbox type | manual gearbox Transmission - Gear shiftcorrect |
|---|---|
| Forward gears | 8correct |
| Reverse gears | 4correct |
| Top speed | 17.4 km/hcorrect |
| Turning radius | 2,530 mmcorrect |
| System voltage | 12 Vcorrect |
Working data
| Lifting capacity | 630 kgcorrect |
|---|---|
| Pump flow | 19.7 l/mincorrect |
| Fuel tank capacity | 38.2 lcorrect |
| PTO output | 20 hpcorrect |
Other data
| Cab height | 2,331.7correct |
|---|
More machines with this engine (KUBOTA D1703-M-DI-E4, 2)
Where this model stands
Power-to-weight ratio: 15.1 kW/t (18 kW / 1.2 t)
Power class: Compact (< 40 hp)
Stronger than 11% of the tractors in the register — out of 14,914 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Kubota L2501-4WD have?
The Kubota L2501-4WD delivers 25.1 hp.
How much does the Kubota L2501-4WD weigh?
The unladen weight is 1,180 kg.
What engine does the Kubota L2501-4WD have?
3 cylinders, 1,647 cm³ displacement.
How fast does the Kubota L2501-4WD go?
Top speed is 17.4 km/h.
What is the PTO output of the Kubota L2501-4WD?
PTO output is 20 hp.
How much does the rear linkage of the Kubota L2501-4WD lift?
The rear linkage lifts 630 kg.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
