Komatsu PC800LC-8

Series: Komatsu Material Handler

Source: https://www.komatsu.eu/en/product-archive/standard-crawler-e

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The PC800LC-8 from Komatsu is part of the Komatsu Material Handler series. The engine delivers 503.1 hp (363 kW), has 6 cylinders, with a displacement of 15,241.6 cm³. Rated speed is 1,800 rpm. Top speed is 4.3 km/h. The tank holds 980 litres. The gearbox has 2 forward gears. The hydraulic tank holds 440.2 litres. The cooling system holds 100.3 litres. The oil fill is 58.3 litres. The electrical system runs on 24 V. The engine fitted is the SAA6D140E-5. The Komatsu Material Handler series covers 5 models. Rated output within it ranges from 439.2 to 697.5 hp; the PC800LC-8 sits in the lower part of that range with 503.1 hp. Its immediate neighbours are the PC600LC-8 below it with 439.2 hp and the PC1250LC-8 above it with 697.5 hp. 1159 Komatsu models across 39 series are on record. The model is listed under Excavators & compaction. 15 verified figures from 1 source are on file.

Technical data

Engine

Engine modelSAA6D140E-5correct
Power503.1 hp (363 kW)correct
Rated speed1,800 rpmcorrect
Cylinders6correct
Displacement15,241.6 cm³correct
Aspirationturbocharged, aftercooledcorrect
Coolant capacity100.3 lcorrect
Engine oil capacity58.3 lcorrect

Drivetrain and chassis

Gearbox typehydrostatic transmissioncorrect
Forward gears2correct
Top speed4.3 km/hcorrect
System voltage24 Vcorrect

Working data

Hydraulic oil capacity440.2 lcorrect
Fuel tank capacity980 lcorrect

Frequently asked questions

How much power does the Komatsu PC800LC-8 have?

The Komatsu PC800LC-8 delivers 503 hp.

What engine does the Komatsu PC800LC-8 have?

6 cylinders, 15,242 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
