Khd Deutz Multitrac
Built: 1955–1959 · Series: Geräteträger
More machines from model year 1955
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Deutz Multitrac – air-cooled implement carrier with a two-cylinder diesel, 1.7-litre displacement and 18 hp from Klöckner-Humboldt-Deutz (1955–1959).
Klöckner-Humboldt-Deutz (KHD), based in Cologne, was known for its air-cooled diesel engines, which need no coolant and are therefore low-maintenance and frost-proof. The Multitrac, built between 1955 and 1959, belongs to the implement-carrier class: vehicles that can mount implements not only at the front and rear but also between the axles.
Read on 3 more paragraphs
The air-cooled two-cylinder diesel engine, with a displacement of 1,700 cm³, delivers 18 hp at 1,800 rpm. With a wheelbase of 1,680 mm and a width of 1,690 mm, the Multitrac is compactly built, at 2,760 mm long and 1,580 mm tall, and reaches a top speed of 20.2 km/h.
Implement carriers such as the Multitrac were designed to carry an implement centrally between the axles, where the driver has a direct view of the working area – an advantage for cultivation and harvesting work in row crops, where precision matters more than high pulling power. Air cooling made the vehicle insensitive to frost and coolant loss, which was an advantage especially for year-round municipal use.
When buying a used Multitrac, the condition of the cooling fins and fan is critical, since contamination impairs the air cooling of the two-cylinder engine. The central implement mount between the axles should be checked for wear and play, as should the steering. Spare parts for this early Deutz model are today mainly available through specialist vintage-vehicle dealers.
Sources: SpecCodex-Register: Kennwerte des Modells Deutz Multitrac, DEUTZ AG
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 18 hpcorrect |
| Rated speed | 1,800 rpmcorrect |
| Cylinders | 2correct |
| Displacement | 1,700 cm³correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 2,760 mmcorrect |
|---|---|
| Width | 1,690 mmcorrect |
| Height | 1,580 mmcorrect |
| Wheelbase | 1,680 mmcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 5V / 1Rcorrect |
| Front tyres | 5.50 - 16correct |
| Rear tyres | 8.3 - 24correct |
| Top speed | 20.2 km/hcorrect |
Origin and approval
| Construction | Zweiholmcorrect |
|---|
Frequently asked questions
How much power does the Khd Deutz Multitrac have?
The Khd Deutz Multitrac delivers 18 hp.
What engine does the Khd Deutz Multitrac have?
2 cylinders, 1,700 cm³ displacement, Diesel.
How fast does the Khd Deutz Multitrac go?
Top speed is 20.2 km/h.
What are the dimensions of the Khd Deutz Multitrac?
2,760 mm × 1,690 mm × 1,580 mm.
When was the Khd Deutz Multitrac built?
Production years: 1955–1959.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
