John Deere/zetor 2400 (A) – specifications
Built: 1993–1996 · Series: 2000er-Baureihe
With the 2400 (A), John Deere/zetor offers a model from the 2000er series. Production: 1993–1996. The engine delivers 74 hp (54.5 kW), has 4 cylinders, with a displacement of 3,922 cm³. Rated speed is 2,200 rpm. The machine is 3,755 mm long, 1,875 mm wide and 2,665 mm high. The unladen weight is 3,200 kg. The wheelbase measures 2,256 mm. Ground clearance is 383 mm. Top speed is 30 km/h. Transmission: 20V/4R. The engine is water-cooled. Tyres: front 7.50-20 ASF (A: 12.4-24 AS), rear 16.9-34 AS. The fuel is diesel. The bore measures 102 mm. The stroke is 120 mm. Construction: unit construction (no separate frame). The 2000er-Baureihe series covers 8 models. Rated output within it ranges from 45 to 105 hp; the 2400 (A) sits in the middle of that range with 74 hp. Its immediate neighbours are the 2300 (A) below it with 70 hp and the 2700 (A) above it with 85 hp. Unladen weight within it ranges from 2,895 to 4,180 kg; here the 2400 (A) sits in the lower part of that range with 3,200 kg. 8 John Deere/zetor models are on record.
Data for the version built 1993–1996 · Data origin: Reference work (Wikipedia/Wikibooks) · sources
More machines from model year 1993
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
John Deere 2000 series built by Zetor – 2000 to 2900: eight three- and four-cylinder diesels built in Brno, 33 to 77 kW, 2.7 to 4.2 litres displacement
The 2000 series is a European utility-tractor range that John Deere had built from 1993 to 1998 at the Brno plant in Czechia – the same plant where Zetor has made its own tractors since 1946. Eight models from 2000 to 2900 order the size in ascending order by type number, most with the suffix (A) marking the version; the 2900 as the largest model of the range reached roughly the power class of John Deere's smaller 6000-series tractors.
Read on 3 more paragraphs
The register lists 8 versions with 33.1 to 77.3 kW from three- and four-cylinders of 2,697 to 4,156 cm³, unladen weights from 2,895 to 4,180 kg, lengths from 3,640 to 4,380 mm and widths from 1,800 to 2,100 mm, at a rated speed of 2,200 rpm.
As all-purpose tractors for grassland, mixed arable farming and municipal tasks, the 2000 series occupied the segment below the large six-cylinder Mannheim ranges in Deere's European line-up and competed there with similarly positioned models from Ford, Massey Ferguson and Zetor's own programme.
On used 2000-series tractors, operating hours and the condition of the three- or four-cylinder diesel count, along with the tightness of the injection pump, the condition of clutch and gearbox, and wear on the rear axle and PTO. Because the range is technically related to Zetor's own programme, many wear parts are comparatively well available through Zetor dealer networks in Central Europe.
Sources: SpecCodex register, model data: John Deere 2000er-Baureihe, John Deere (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 74 hp (54.5 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,922 cm³correct |
| Bore | 102 mmcorrect |
| Stroke | 120 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,755 mmcorrect |
|---|---|
| Width | 1,875 mmcorrect |
| Height | 2,665 mmcorrect |
| Wheelbase | 2,256 mmcorrect |
| Ground clearance | 383 mmcorrect |
| Unladen weight | 3,200 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 20V/4Rcorrect |
| Front tyres | 7.50-20 ASF (A: 12.4-24 AS)correct |
| Rear tyres | 16.9-34 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Frequently asked questions
Where this model stands
Power-to-weight ratio: 17 kW/t (54 kW / 3.2 t)
Power class: Universal (40–100 hp)
Stronger than 51% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
