John Deere 9320 T

Built: 2002–2007 · Series: 9020er-Baureihe

More machines from model year 2002

Source: https://www.tractordata.com/farm-tractors/001/3/7/1379-john-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 9320 T, John Deere offers a model from the 9020er series. Production: 2002–2007. The engine delivers 375 hp (276 kW), has 6 cylinders, with a displacement of 12,536 cm³. Rated speed is 2,100 rpm. The machine is 6,020 mm long, 3,454 mm wide and 3,454 mm high. The unladen weight is 19,436 kg. The wheelbase measures 2,810 mm. Ground clearance is 375 mm. Top speed is 30 km/h. The tank holds 1,034 litres. Transmission: 18V/6R or 24V/6R. The engine is water-cooled. Tyres: front 760 x 2.819 mm, rear 760 x 2.819 mm. The fuel is diesel. The bore measures 127 mm. The stroke is 165 mm. The compression ratio is 17:1. Construction: frame construction. The linkage is category III. The 9020er-Baureihe series covers 4 models. Rated output within it ranges from 375 to 500 hp; the 9320 T sits at the bottom of that range with 375 hp. Its immediate neighbours are the 9420 T above it with 425 hp. Unladen weight within it ranges from 16,676 to 19,436 kg; here the 9320 T sits at the top of that range with 19,436 kg. 2622 John Deere models across 140 series are on record.

John Deere 9020T Series – articulated rubber-tracked tractors (2002 to 2007) spanning 9320T to 9620T, six-cylinder engine displacing 12,536 cc, 276 to 368 kW at 2,100 rpm

John Deere built the 9020 Series from 2002 to 2007 as articulated high-power tractors, and the T models listed here – 9320T, 9420T, 9520T and 9620T – carry rubber tracks instead of wheels on both frame halves. All four models share the same six-cylinder engine displacing 12,536 cc at 2,100 rpm rated speed, with the type number rising with the power class. The series complemented the wheeled 9020 models with a tracked variant for especially heavy soils.

Read on 3 more paragraphs

The register lists here 4 versions with 276 to 368 kW (375 to 500 hp) rated output. Unladen weights range from 16,676 to 19,436 kg, length is 6,020 mm, height 3,454 mm; width varies with track gauge and track width from 3,454 to 3,952 mm.

The combination of articulated steering and track undercarriage aimed the 9020T Series at large operations with high flotation demands, such as tillage and seeding on heavy or wet soils, competing with the Case IH Quadtrac and the Challenger MT700B. The large six-cylinder with its high drawbar pull made the machines a first choice for large-scale tillage.

When buying used, check the condition of the rubber tracks and mid-rollers, the tightness of the articulation-joint hydraulics, the hours and service history of the six-cylinder, and wear on the drive wheels and tensioning system. Parts and service run through the John Deere dealer network.

Sources: SpecCodex register, model data: John Deere 9020er-Baureihe, John Deere (manufacturer)

Technical data

Engine

Fuel	dieselcorrect
Power	375 hp (276 kW)correct
Rated speed	2,100 rpmcorrect
Cylinders	6correct
Displacement	12,536 cm³correct
Bore	127 mmcorrect
Stroke	165 mmcorrect
Compression ratio	17correct
Cooling	water-cooledcorrect

Dimensions and weights

Length	6,020 mmcorrect
Width	3,454 mmcorrect
Height	3,454 mmcorrect
Wheelbase	2,810 mmcorrect
Ground clearance	375 mmcorrect
Unladen weight	19,436 kgcorrect

Drivetrain and chassis

Drive	track drivecorrect
Gearbox	18V/6R or 24V/6Rcorrect
Front tyres	760 x 2.819 mmcorrect
Rear tyres	760 x 2.819 mmcorrect
Top speed	30 km/hcorrect

Working data

Fuel tank capacity	1,034 lcorrect

Origin and approval

Construction	frame constructioncorrect

Other data

Linkage category	Cat IIIcorrect

Where this model stands

Power-to-weight ratio: 14.2 kW/t (276 kW / 19.4 t)

Power class: Heavy (> 180 hp)

Stronger than 98% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the John Deere 9320 T have?

The John Deere 9320 T delivers 375 hp.

How much does the John Deere 9320 T weigh?

The unladen weight is 19,436 kg.

What engine does the John Deere 9320 T have?

6 cylinders, 12,536 cm³ displacement, Diesel.

How fast does the John Deere 9320 T go?

Top speed is 30 km/h.

What are the dimensions of the John Deere 9320 T?

6,020 mm × 3,454 mm × 3,454 mm.

When was the John Deere 9320 T built?

Production years: 2002–2007.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
