John Deere 300D (212.5 kW)
Series: John Deere Articulated Dump Truck
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
John Deere articulated dump trucks 250C to 460E – built by Bell in South Africa: the number as payload in short tons times ten, Mercedes engines in the C and D generation, Deere engines from the E generation, 177 to 359 kW
John Deere's articulated haulers are Bell designs: since 1999 Deere has worked with Bell Equipment of Richards Bay, South Africa, the specialist that builds the haulers for Deere in yellow – and the register rows prove it, because the C and D models carry Mercedes-Benz engines OM 366, OM 442, OM 501 and OM 906 as Bell uses them. The type logic: the number gives the payload in short tons times ten – 250 about 25 t, 300 30 t, 350 35 t, 400 40 t, 460 46 t – C and D are the generations of the 2000s, E the generation from 2011, in which Deere used its own PowerTech 6135 and 6090 engines in the 410E and 460E and partly moved production to Davenport, Iowa; the 300D Water Wagon is the chassis for water-tank bodies for dust suppression.
Read on 3 more paragraphs
The register lists 11 versions with 176.7 to 358.7 kW from six-cylinders of 5,949 to 15,076 cm³, torque from 803 to 2,285 Nm at 1,800 to 2,500 rpm, lengths from 9,168 to 11,531 mm, widths from 2,743 to 3,810 mm and heights from 3,380 to 4,260 mm.
The Bell design with the single engine up front, the oscillating hitch between tractor and body and the Allison transmission is common in North America in Deere colours; the 460E with 46 t payload belongs to the largest class of articulated haulers, in which only Volvo and Bell itself carry more.
On used trucks, operating hours, play in articulation joint and oscillation bearings, the condition of body cylinders, brakes and transmission and the tyres count; parts run through Deere dealers, for Mercedes engines also through their network.
Sources: Kennwerte der Modelle John Deere knickgelenkte Muldenkipper, John Deere Articulated Dump Trucks (Hersteller)
Technical data
Engine
| Engine model | 6,090correct |
|---|---|
| Power | 212.5 kWcorrect |
| Rated speed | 2,200 rpmcorrect |
| Torque | 1,069.7correct |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 8,996.5 cm³correct |
| Aspiration | Turbocharger charge air cooledcorrect |
| Coolant capacity | 32.9 lcorrect |
| Engine oil capacity | 25.4 lcorrect |
Dimensions and weights
| Length | 9,582.9correct |
|---|---|
| Width | 2,950.5correct |
| Height | 3,480 mmcorrect |
| Wheelbase | 5,010.9correct |
| Ground clearance | 432.8correct |
Drivetrain and chassis
| Gearbox type | ZF 6HP592C fully automatic gearboxcorrect |
|---|---|
| Forward gears | 6correct |
| Reverse gears | 1correct |
| Tyre size | 23.5R25correct |
| Top speed | 49.9 km/hcorrect |
Working data
| Hydraulic oil capacity | 78.7 lcorrect |
|---|---|
| Fuel tank capacity | 340.7 lcorrect |
Other data
| System voltage | 24 Vcorrect |
|---|
More machines with this engine (6090, 3)
Frequently asked questions
How much power does the John Deere 300D have?
The John Deere 300D delivers 212 kW.
What engine does the John Deere 300D have?
6 cylinders, 8,996 cm³ displacement.
How fast does the John Deere 300D go?
Top speed is 49.9 km/h.
What are the dimensions of the John Deere 300D?
9,583 mm × 2,950 mm × 3,480 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
