John Deere 200C LC

Series: John Deere Hydraulic Excavator

Source: https://www.deere.com.au/en/forwarders/2010h/

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere 200C LC belongs to the John Deere Hydraulic Excavator series. The engine delivers 105.1 kW, has 6 cylinders, with a displacement of 6,784.2 cm³. Torque is 579.1 Nm. Rated speed is 2,150 rpm. The unladen weight is 20,924.2 kg. Ground clearance is 451.1 mm. The tank holds 360.4 litres. Maximum torque is reached at 1,300 rpm. The pump delivers 438.4 l/min. The hydraulic tank holds 128.7 litres. Working pressure is 343.4 bar. The engine fitted is the 6068H. The John Deere Hydraulic Excavator series covers 82 models. Rated output within it ranges from 48.5 to 396.7 kW; the 200C LC sits in the lower part of that range with 105.1 kW. Its immediate neighbours are the 200 LC below it with 104.4 kW and the 225C LC RTS above it with 109.6 kW. 2153 John Deere models across 96 series are on record. The model is listed under Excavators & compaction. 14 verified figures from 1 source are on file.

Technical data

Engine

Engine model6068Hcorrect
Power105.1 kWcorrect
Rated speed2,150 rpmcorrect
Torque579.1correct
Speed at max. torque1,300 rpmcorrect
Cylinders6correct
Displacement6,784.2 cm³correct
Aspirationturbochargedcorrect

Dimensions and weights

Ground clearance451.1correct
Unladen weight20,924.2 kgcorrect

Working data

Pump flow438.4 l/mincorrect
Hydraulic oil capacity128.7 lcorrect
Hydraulic pressure343.4 barcorrect
Fuel tank capacity360.4 lcorrect

Where this model stands

Power-to-weight ratio: 5 kW/t (105 kW / 20.9 t)

Stronger than 44% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the John Deere 200C LC have?

The John Deere 200C LC delivers 105 kW.

How much does the John Deere 200C LC weigh?

The unladen weight is 20,924 kg.

What engine does the John Deere 200C LC have?

6 cylinders, 6,784 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
