John Deere 110

Series: John Deere Hydraulic Excavator

Wikimedia Commons · Public domain · Rob Melendez · Dateiseite
The John Deere 110 belongs to the John Deere Hydraulic Excavator series. The engine delivers 59.7 kW, has 4 cylinders, with a displacement of 4,522.8 cm³. Torque is 330.8 Nm. Rated speed is 2,200 rpm. The unladen weight is 12,292.4 kg. Ground clearance is 457.2 mm. The tank holds 249.8 litres. Maximum torque is reached at 1,300 rpm. The pump delivers 98.4 l/min. The hydraulic tank holds 132.5 litres. Working pressure is 343.4 bar. The cooling system holds 22.3 litres. The oil fill is 13.2 litres. The electrical system runs on 24 V. The engine fitted is the 4045 T. The John Deere Hydraulic Excavator series covers 82 models. Rated output within it ranges from 48.5 to 396.7 kW; the 110 sits at the bottom of that range with 59.7 kW. Its immediate neighbours are the 490D below it with 55.9 kW and the 490E above it with 63.4 kW. 2153 John Deere models across 96 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine model4045 Tcorrect
Power59.7 kWcorrect
Rated speed2,200 rpmcorrect
Torque330.8correct
Speed at max. torque1,300 rpmcorrect
Cylinders4correct
Displacement4,522.8 cm³correct
AspirationTurbochargercorrect
Coolant capacity22.3 lcorrect
Engine oil capacity13.2 lcorrect

Dimensions and weights

Ground clearance457.2correct
Unladen weight12,292.4 kgcorrect

Drivetrain and chassis

System voltage24 Vcorrect

Working data

Pump flow98.4 l/mincorrect
Hydraulic oil capacity132.5 lcorrect
Hydraulic pressure343.4 barcorrect
Fuel tank capacity249.8 lcorrect

Other data

Height2,721.9correct

Where this model stands

Power-to-weight ratio: 4.9 kW/t (60 kW / 12.3 t)

Stronger than 18% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the John Deere 110 have?

The John Deere 110 delivers 59.7 kW.

How much does the John Deere 110 weigh?

The unladen weight is 12,292 kg.

What engine does the John Deere 110 have?

4 cylinders, 4,523 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 18 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
